Diagnostics

9.3.3 Trace Signals

Signal ID (hex) Signal name
00000015 DC-link voltage
0000003D Warning code
0000003E Error code
0000005A Temperature control card
0000005B Temperature power card
0000005C Temperature SAB card
00004019 External encoder position
0000401A External encoder speed
0000404D UDC 1 current
0000404E UDC 2 current
0000404F AUX line 1 current
00004050 AUX line 2 current
00004051 AUX line voltage
00004052 Brake Chopper Gate
00004053 Brake Chopper Feedback
00007D00 UDC Over-Inrush
00007D01 UDC Bypass-Inrush
00007D02 UDC Back Current
00007D03 Inrush relay power card
00007D04 Inrush relay SAB card
00007D05 DC leakage current
00007D06 Brake resistor power monitoring
00007D07 DC link total current
00007D08 DC link total current raw
00007D09 UDC 1 flow (filtered)
00007D0A UDC 2 flow (filtered)
80000012 Controlword
80000013 Statusword
80010025 Position guide value reference
80010026 Velocity guide value reference
Table 9.6 Trace Signals for SAB
MG36D102
Programming Guide
PLC library -
trace constant name
SAB_TRC_V_DC
SAB_TRC_WARNING
SAB_TRC_ERROR
–
–
–
SAB_TRC_EXT_ENC_POSITION
SAB_TRC_EXT_ENC_SPEED
SAB_TRC_I_DC_LINE_1
SAB_TRC_I_DC_LINE_2
SAB_TRC_I_AUX_LINE_1
SAB_TRC_I_AUX_LINE_2
SAB_TRC_UAUX
SAB_TRC_BRAKE_CH_GATE
SAB_TRC_BRAKE_CH_FEEDB
SAB_TRC_I_INRUSH
SAB_TRC_I_NORMAL
SAB_TRC_I_BACK
SAB_TRC_INRUSH_RELAY_PC
SAB_TRC_INRUSH_RELAY_SC
SAB_TRC_I_DC_LEAKAGE
SAB_TRC_BRAKE_PWR_MON
SAB_TRC_I_DC_SUM
SAB_TRC_I_DC_SUM_RAW
SAB_TRC_I_DC_LINE_1_FILT
SAB_TRC_I_DC_LINE_2_FILT
SAB_TRC_CONTROLWORD
SAB_TRC_STATUSWORD
SAB_TRC_POS_GUIDE_REF
SAB_TRC_VEL_GUIDE_REF
Danfoss A/S © 01/2017 All rights reserved.
Description
DC-link voltage
Warning code
Error code
Temperature control card
Temperature power card
Temperature SAB card
External encoder position
External encoder speed
Current flow on DC link line 1
Current flow on DC link line 2
Current on AUX Line 1
Current on AUX Line 2
AUX line voltage
Brake chopper gate
Brake chopper feedback
UDC current over-inrush
UDC current bypass-inrush
Current (link voltage) back from drives
Inrush relay power card
Inrush relay SAB card
DC leakage current
Brake resistor power monitoring
DC link total current
DC link total current (unfiltered)
Current flow on DC link line 1 (filtered)
Current flow on DC link line 2 (filtered)
Controlword
Statusword
Position guide value reference
Velocity guide value reference
OD object
0x 2003
0x 5FFE
0x 603F
0x 2000.2
0x 2000.1
0x 2000.3
0x 2011.1
0x 2011.2
0x 2001.2
0x 2001.3
0x 2003.2
0x 2003.3
0x 2003.1
–
–
0x 2002.5
0x 2002.6
0x 2002.7
–
9 9
–
0x 2001.5
0x 2033
0x 2001.1
0x 2001.7
0x 2001.8
0x 6040
0x 6041
0x 2062
0x 2065
