7.18.4 Parameter 51-54: Touch Probe 1 Negative Edge (0x60BB)

This object provides the position value of touch probe 1 at negative edge. The value is given in user-defined position units.
Attribute
Index
LCP parameter number
Name
Object code
Data type
Sub-index
Access
PDO mapping
Value range
Default value
Table 7.188 0x60BB: Touch Probe 1 Negative Edge

7.18.5 Parameter 51-61: Touch Probe 2 Positive Edge (0x60BC)

This object provides the position value of the touch probe 2 at positive edge. The value is given in user-defined position
units.
Attribute
Index
LCP parameter number
Name
Object code
Data type
Sub-index
Access
PDO mapping
Value range
Default value
Table 7.189 0x60BC: Touch Probe 2 Positive Edge

7.18.6 Parameter 51-64: Touch Probe 2 Negative Edge (0x60BD)

This object provides the position value of touch probe 2 at negative edge. The value is given in user-defined position units.
Attribute
Index
LCP parameter number
Name
Object code
Data type
Sub-index
Access
PDO mapping
Value range
MG36D102
Programming Guide
Value
0x60BB
51-54
Touch probe 1 negative edge
Var
INTEGER32
0x00
Read only
Optional
INTEGER32
–
Value
0x60BC
51-61
Touch probe 2 positive edge
Var
INTEGER32
0x00
Read only
Optional
INTEGER32
–
Value
0x60BD
51-64
Touch probe 2 negative edge
Var
INTEGER32
0x00
Read only
Optional
INTEGER32
