SAB Parameter Description
Attribute Value
Sub-index 0x03
LCP Parameter number 12-02
Name IP mask
Data type UNSIGNED32
Access Read only
PDO mapping Yes
Value range 0x0000 0000–0xFFFF FFFF
Default value 0
Sub-index 0x04
LCP Parameter number 12-03
Name IP gateway
Data type UNSIGNED32
Access Read only
PDO mapping Yes
Value range 0x0000 0000–0xFFFF FFFF
Default value –
Sub-index 0x08
LCP Parameter number 12-04
Name Mac address
Data type OCTET_STRING
Access Read only
PDO mapping Yes
Value range –
Default value –
Sub-index 0x0D
LCP Parameter number –
Name Network topology
Data type UNSIGNED8
Access Read/write
PDO mapping No
Value range 0, 1
Default value 0
Table 8.24 0x400A: Communication Settings

8.30 Object 0x5020: Control Source

This object shows the control source for the SAB.
•
Value 0: Fieldbus is in control (writes are only
accepted from the fieldbus).
•
Value 1: The LCP is in control (writes are only
accepted from the LCP).
Attribute
Index
Description
Object code
Data type
Sub-index
LCP parameter number
Access
MG36D102
Programming Guide

8.31 Object 0x5807: Total Running Time

The SAB has 2 counters for the running time:
Value
0x5020
Control source
Var
UNSIGNED16
0x00
–
Read/write
Danfoss A/S © 01/2017 All rights reserved.
Attribute
PDO mapping
Value range
Default value
Table 8.25 Object 0x5020: Control Source
•
Non-resettable counter (32 bits)
- Counts the time that the SAB has been
running in state Normal operation in
seconds.
•
Resettable counter
-
Counts the time that the SAB has been
running in state Normal operation in
seconds.
- Can be reset by writing 0 to it and can
therefore be used to track service
intervals.
Attribute
Index
Description
Object code
Sub-index
LCP parameter number
Description
Access
PDO mapping
Value range
Default value
Sub-index
LCP parameter number
Description
Access
PDO mapping
Object code
Data type
Sub-index
LCP parameter number
Description
Access
PDO mapping
Object code
Data type
Table 8.26 Object 0x5807: Total Running Time
Value
Yes
0 or 1
0
Value
0x5807
Total running time
Array
0x00
–
Number of entries
Read only
No
0x02
0x02
0x01
15-01
Total running time SAB
Read only
Yes
Var
UNSIGNED32
0x02
15-02
Total running time user
Read/write
Yes
Var
UNSIGNED32
365
