Programming
Variable Data Default
name type value
VAR_IN_OUT
Axis AXIS_REF_ISD51x
VAR_INPUT
Enable BOOL FALSE
VAR_OUTPUT
Valid BOOL
Busy BOOL
Error BOOL
ErrorInfo DD_ERROR_ISD51x
ConstantVe- BOOL
locity
Standstill BOOL
Accelerating BOOL
Decelerating BOOL
Direction- BOOL
Positive
Direction- BOOL
Negative
LimitActive BOOL
Table 6.11 MC_ReadMotionState_ISD51x
6.5.4.11 MC_ReadActualPosition_ISD51x
This function block provides the value of the actual
position if Enable is set (see chapter 7.7.5 Parameter 50-03:
Position Actual Value (0x6064)). Valid is TRUE when the data-
output Position is valid. If Enable is reset, the data loses its
validity and all outputs are reset, regardless of whether
new data is available.
The output Position is a signed value.
The output data is available immediately.
MG36D102
Programming Guide
Description
Reference to the axis.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
Get the value of the
parameters continuously
while enabled.
The function block has a
valid set of outputs.
The function block is not
finished and new output
values are to be expected.
An error has occurred
within the function block.
Error identification and
instance identifier.
See chapter 6.5.2.3 Error
Indication.
Velocity is constant.
Velocity may be 0. For the
actual value, a window is
applicable, see
chapter 7.22.3.1 Parameter
51-70: Constant Velocity
Window (0x2030) and
chapter 7.22.3.2 Parameter
51-71: Constant Velocity
Window Time (0x2031).
Velocity is constant and
value 0.
Increasing the absolute
value of the velocity.
Decreasing the absolute
value of the velocity.
The position is increasing.
The position is decreasing.
An internal limit is active.
Danfoss A/S © 01/2017 All rights reserved.
MC_ReadActualPosition_ISD51x
AXIS_REF_- Axis
ISD51x
BOOL Enable
Illustration 6.34 MC_ReadActualPosition_ISD51x
Variable Data Default
name type value
VAR_IN_OUT
Axis AXIS_REF_ISD51x
VAR_INPUT
Enable BOOL FALSE
VAR_OUTPUT
Valid BOOL
Busy BOOL
Error BOOL
ErrorInfo DD_ERROR_ISD51x
Position DINT
Table 6.12 MC_ReadActualPosition_ISD51x
6.5.4.12 MC_ReadActualVelocity_ISD51x
This function block provides the value of the actual
velocity if Enable is set (see chapter 7.11.3 Parameter 50-04:
Velocity Actual Value (0x606C)). Valid is TRUE when the data-
output Velocity is valid. If Enable is reset, the data loses its
validity and all outputs are reset, regardless of whether
new data is available.
The output Velocity is a signed value.
The output data is available immediately.
Valid BOOL
Busy BOOL
Error BOOL
ErrorInfo DD_ERROR_ISD51x
Position DINT
Description
Reference to the axis.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
Get the value of the
parameter continuously
while enabled.
The function block has a
valid output.
The function block is not
finished and new output
values are to be expected.
An error has occurred
within the function block.
Error identification and
instance identifier.
See chapter 6.5.2.3 Error
Indication.
New absolute position
[user-defined position
unit].
183
6 6
