Programming
AXIS_REF_-
ISD51x
BOOL
USINT
Illustration 6.52 DD_SelectControlParamSet_ISD51x
Variable
name
6 6
VAR_IN_OUT
Axis
VAR_INPUT
Enable
Set
VAR_OUTPUT
Valid
Busy
Error
ErrorInfo
Table 6.29 DD_SelectControlParamSet_ISD51x
6.5.4.27 MC_TouchProbe_ISD51x
This function block is used to record the axis position at a
trigger event. This functionality is intended for single shot
operation: The 1
recorded, however the events after that are ignored. 1
function block instance should represent exactly 1 trigger
input.
The activation of the touch probe functionality can take
some time.
194
DD_SelectControlParamSet_ISD51x
Axis
Enable Valid
Set Busy
Error
ErrorInfo
Data Default Description
type value
AXIS_REF_ISD51x Reference to the axis.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
BOOL FALSE Selects the control
parameter set.
USINT 1 Number of the control
parameter set to be used.
Values: 1 or 2
BOOL The function block has a
valid output.
BOOL The function block is not
finished and new output
values are to be expected.
BOOL An error has occurred
within the function block.
DD_ERROR_ISD51x Error identification and
instance identifier.
See chapter 6.5.2.3 Error
Indication.
st
event after the rising edge of Execute is
