Programming
6.5.4.16 MC_ReadDigitalOutput_ISD51x
This function block provides the value of the digital
output. It is not guaranteed that short pulses on the digital
signal can be seen on the function block.
The output data is available immediately.
AXIS_REF_-
ISD51x
BOOL
6 6
Illustration 6.39 MC_ReadDigitalOutput_ISD51x
Variable
name
VAR_IN_OUT
Output
VAR_INPUT
Enable
VAR_OUTPUT
Valid
Busy
Error
ErrorInfo
Value
Table 6.17 MC_ReadDigitalOutput_ISD51x
186
MC_ReadDigitalOutput_ISD51x
Output
Enable Valid
Busy
Error
ErrorInfo
Value
Data Default Description
type value
AXIS_REF_ISD51x Reference to the axis.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
BOOL FALSE Get the value of the
output signal continuously
while enabled.
BOOL The function block has a
valid output.
BOOL The function block is not
finished and new output
values are to be expected.
BOOL An error has occurred
within the function block.
DD_ERROR_ISD51x Error identification and
instance identifier.
See chapter 6.5.2.3 Error
Indication.
BOOL The value of the output
signal.
Danfoss A/S © 01/2017 All rights reserved.
®
VLT Integrated Servo Drive ISD
6.5.4.17 DD_WriteDigitalOutput_ISD51x
This function block writes a value to the digital output of
the axis. If Enable is TRUE, the input Value is evaluated. If
the input Enable is FALSE, the last value is used. This
function block only works if the usage of the digital output
is configured accordingly (see chapter 7.21.5 Parameter
52-05: Digital Output Configuration (0x2FFF)).
AXIS_REF_-
BOOL
ISD51x
BOOL
BOOL
BOOL
DD_ERROR_ISD51x
BOOL
BOOL
Illustration 6.40 DD_WriteDigitalOutput_ISD51x
Variable
name
VAR_IN_OUT
Output
VAR_INPUT
Enable
Value
VAR_OUTPUT
Valid
Busy
Error
ErrorInfo
Table 6.18 DD_WriteDigitalOutput_ISD51x
®
510 System
DD_WriteDigitalOutput_ISD51x
Output
Enable
Value
ErrorInfo
Data Default Description
type value
AXIS_REF_ISD51x Reference to the axis/
signal output.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
BOOL FALSE Write the value of the
digital output.
BOOL FALSE Value of the output:
TRUE = set
FALSE = clear
BOOL The function block has a
valid output.
BOOL The function block is not
finished and new output
values are to be expected.
BOOL An error has occurred
within the function block.
DD_ERROR_ISD51x Error identification and
instance identifier.
See chapter 6.5.2.3 Error
Indication.
Valid BOOL
Busy BOOL
Error BOOL
DD_ERROR_-
ISD51x
