  • Page 1 MAKING MODERN LIVING POSSIBLE Operating Instructions ® Extended Relay Card MCB 113 VLT® AutomationDrive FC 300...

  • Page 2: Table Of Contents

    Electrical Data Ordering Numbers 4 How to Install Installation of Option in the Frequency Converter 5 Parameter Set-up 5-** Digital In/Out 6-** Analog Outputs 14-** 24 V DC External Supply 16-** Data readouts MI.33.G3.02 - VLT® is a registered Danfoss trademark...
  • Page 3 FC 300 Extended Relay Card Operating In- 1 How to Read these Operating Instructions structions MI.33.G3.02 - VLT® is a registered Danfoss trademark...

  • Page 4: How To Read These Operating Instructions

    Chapter 5, Parameter Set-up, shows the parameter settings associated with the VLT Extended Relay Card MCB 113. 1.1.1 Approvals 1.1.2 Symbols Symbols used in this Operating Instructions. Indicates something to be noted by the reader. Indicates a general warning. Indicates a high-voltage warning. ∗ Indicates default setting MI.33.G3.02 - VLT® is a registered Danfoss trademark...

  • Page 5: Abbreviations

    NAMUR NE37 German recommendations, commonly used within the Chemical Industry ”Realisation of Frequency Converters Standard Terminal Strip for Variable-speed Drives” Ampere/AMP Alternating current Direct current Electromagnetic Compatibility Hertz Parameter par. Volts Mili MI.33.G3.02 - VLT® is a registered Danfoss trademark...

  • Page 6: Safety And Conformity

    Control signals from, or internally within, the frequency converter may in rare cases be activated in error, be delayed or fail to occur entirely. When used in situations where safety is critical, e.g. when controlling the electromagnetic brake function of a hoist application, these control signals must not be relied on exclusively. MI.33.G3.02 - VLT® is a registered Danfoss trademark...
  • Page 7 30 minutes For further information, please see the VLT Automation Drive FC 300 Operating Instructions, MG.33.AX.YY or the VLT Automation Drive FC 300 Design Guide, MG.33.BX.YY x = version number y = language MI.33.G3.02 - VLT® is a registered Danfoss trademark...

  • Page 8: Introduction To Extended Relay Card Mcb 113

    3 Introduction to Extended Relay Card MCB 113 The VLT Extended Relay Card MCB 113 is constructed as a standard C1 option for the Danfoss VLT AutomationDrive FC 300 and is automatically detected after mounting. The MCB 113 adds 7 digital inputs, 2 analog outputs and 4 SPDT relays to the standard I/O of the frequency converter which makes it possible to comply with the German NAMUR NE37 recommendations.

  • Page 9: Connection Schematic - Following Namur

    I/O Mode 3.1.2 Connection Schematic - Following NAMUR In NAMUR terminology. Control Card Internal 24 VDC MCB 113 Par. 14-80 Analogue Out Digital In Rin = 4kΩ 0/4-20 mA X58/ 24 VDC MI.33.G3.02 - VLT® is a registered Danfoss trademark...

  • Page 10: Galvanic Isolation

    Number Range 0/4 -20 mA Resolution 11 bit Linearity < 0.2% IEC 61000-6-2 and IEC 61800-3 regarding Immunity of BURST, ESD, SURGE and Conducted Immunity 3.1.5 Ordering Numbers 130B1164 (Non-coated) 130B1264 (Coated) MI.33.G3.02 - VLT® is a registered Danfoss trademark...
  • Page 11 FC 300 Extended Relay Card Operating In- 4 How to Install structions MI.33.G3.02 - VLT® is a registered Danfoss trademark...

  • Page 12: How To Install

    B3 (60 mm for C0 + C1 option) 130B1414 Compact 130B7532 B, C, D, E and F (except B3) 130B7533 Enclosure A5 - C For these enclosures only one C option can be installed at a time. MI.33.G3.02 - VLT® is a registered Danfoss trademark...
  • Page 13 Illustration 4.1: 1. The 40 mm mounting kit is used when only one C option is used. 2. The 60 mm mounting kit is used when the MCB 113 is used together with the MCO 305. MI.33.G3.02 - VLT® is a registered Danfoss trademark...

  • Page 14: Parameter Set-Up

    FC 300 standard terminals are 18, 19, 27, 29, 32 and 33. MCB 101 terminals are X30/2, X30/3 and X30/4. Terminal 29 functions as an output only in FC 302. Functions dedicated to only one digital input are stated in the associated parameter. MI.33.G3.02 - VLT® is a registered Danfoss trademark...
  • Page 15 Freezes the actual reference, which is now the point of enable/condition for Speed up and Speed down to be used. If Speed up/down is used, the speed change always follows ramp 2 MI.33.G3.02 - VLT® is a registered Danfoss trademark...
  • Page 16 Edge triggered pulse input counts number of pulse flanks per sample time. This gives a higher resolution at high frequencies, but is not as precise at lower frequencies. Use this pulse principle for encoders with very low resolution (e.g. 30 ppr). MI.33.G3.02 - VLT® is a registered Danfoss trademark...
  • Page 17 Brake feedback for hoisting applications: Set par. 1-01 feedback ; set par. 1-72 Start Function to [6] Hoist mech brake Ref. [71] Mech. Brake Feedback inv. Inverted brake feedback for hoisting applications MI.33.G3.02 - VLT® is a registered Danfoss trademark...
  • Page 18 5-26 Terminal X46/13 Digital Input Option: Function: [0] * No operation This parameter is active when option module MCB 113 is installed in the frequency converter. Func- Digital Inputs tions are described under 5-1* MI.33.G3.02 - VLT® is a registered Danfoss trademark...
  • Page 19 Output is Logic ‘1’ when the brake IGBT is short-circuited. Use this function to protect the frequency converter if there is a fault on the brake modules. Use the output/relay to cut out the main voltage from the frequency converter. MI.33.G3.02 - VLT® is a registered Danfoss trademark...
  • Page 20 SL Digital Output C See par. 13-52 Set dig. out. A high is executed. The input will go low whenever the Smart Logic Action [34] Set dig. out. A low is executed. MI.33.G3.02 - VLT® is a registered Danfoss trademark...
  • Page 21 Output speed is higher than the speed set in par. 1-81 Min Speed for Function at Stop [RPM] Min Speed for Function at Stop [RPM]. The motor is running and no warnings. MI.33.G3.02 - VLT® is a registered Danfoss trademark...
  • Page 22 Activate relay 1 by control word from fieldbus. No other functional impact in the frequency converter. Typical application: controlling auxiliary device from fieldbus. The function is valid when FC profile [0] in par par. 8-10 Control Word Profile is selected. MI.33.G3.02 - VLT® is a registered Danfoss trademark...
  • Page 23 Otherwise, it will be low. [80] SL digital output A See par. 13-52 SL Controller Action . Output A is low on Smart Logic Action [32]. Output A is high on Smart Logic Action [38]. MI.33.G3.02 - VLT® is a registered Danfoss trademark...
  • Page 24 Output is high when the frequency converter is in Hand on mode (as indicated by the LED light above [Hand on]). [126] Drive in auto mode Output is high when the frequency converter is in ‘Auto’ mode (as indicated by LED on above [Auto On]). MI.33.G3.02 - VLT® is a registered Danfoss trademark...
  • Page 25 [0.01 - 600.00 s.] Selected Event Relay output On Delay O Delay P 5-41 P 5-42 If the Selected Event condition changes before the on- or off delay timer expires, the relay output is unaffected. MI.33.G3.02 - VLT® is a registered Danfoss trademark...

  • Page 26: Analog Outputs

    The torque setting is related to setting in par. 4-16 [135] Torque % nom 4-20 mA The torque setting is related to the motor torque setting. [136] Power 4-20 mA Taken from par. 1-20 Motor Power [kW] MI.33.G3.02 - VLT® is a registered Danfoss trademark...
  • Page 27 Holds the preset level of Analog Output 3 (terminal X45/1). Terminal X45/1 Output the In case of a bus timeout and a timeout function is selected in par. 6-70 output will preset to this level. MI.33.G3.02 - VLT® is a registered Danfoss trademark...

  • Page 28: 24 V Dc External Supply

    Select Yes [1] if an external 24 V DC supply will be used to power the option. Inputs/Outputs will be galvanically isolated from the drive when operated from an external supply. This parameter is only changing function by performing a power cycle. MI.33.G3.02 - VLT® is a registered Danfoss trademark...

  • Page 29: Data Readouts

    DI T -27 DI T -19 DI T -18 DI T -37 DI X30/4 DI X30/3 DI X30/2 DI X46/13 DI X46/11 DI X46/9 DI X46/7 DI X46/5 DI X46/3 DI X46/1 MI.33.G3.02 - VLT® is a registered Danfoss trademark...
  • Page 30 16-79 Analog Out X45/3 [mA] Range: Function: 0.000* [0.000 - 30.000 ] View the actual value at output X45/3. The value shown reflects the selection in par. 6-80 Terminal X45/3 Output . MI.33.G3.02 - VLT® is a registered Danfoss trademark...
