Programming
Variable Data Default
name type value
Busy BOOL
Error BOOL
ErrorInfo DD_ERROR_ISD51x
Communica- BOOL
tionReady
ReadyFor- BOOL
PowerOn
PowerOn BOOL
SabWarning BOOL
SabError BOOL
Table 6.73 DD_ReadSabInfo_SAB
6.5.8.5 DD_ReadSabError_SAB
This function block presents general SAB errors unrelated
to the function blocks (for example, overtemperature in
the SAB). The output SabErrorID gives the last error that
occurred in the SAB (see chapter 9.3.2 Warnings and
Alarms).
The output data needs to be read from the device and is
therefore not immediately available.
DD_ReadSabError_SAB
SAB_REF Sab
BOOL Enable
Illustration 6.88 DD_ReadSabError_SAB
MG36D102
Programming Guide
Description
The function block is not
finished and new output
values are to be expected.
An error has occurred within
the function block.
Error identification and
instance identifier.
See chapter 6.5.2.3 Error
Indication.
Network is initialized and
ready for communication.
SAB is ready to enable the
power on the lines (mains
voltage is applied on the
SAB).
TRUE shows that the power is
switched on at the output
lines.
Warning(s) present on the
SAB.
Error(s) present on the SAB.
Valid BOOL
Busy BOOL
Error BOOL
ErrorInfo DD_ERROR_ISD51x
SabErrorID WORD
Danfoss A/S © 01/2017 All rights reserved.
Variable Data Default
name type value
VAR_IN_OUT
Sab SAB_REF
VAR_INPUT
Enable BOOL FALSE
VAR_OUTPUT
Valid BOOL
Busy BOOL
Error BOOL
ErrorInfo DD_ERROR_ISD51x
SabErrorID WORD
Table 6.74 DD_ReadSabError_SAB

6.5.8.6 DD_ReadSabWarning_SAB

This function block presents general SAB warnings
unrelated to the function blocks (for example, high
temperature in the SAB). The output SabWarningID gives
the last warning that occurred in the SAB (see
chapter 9.3.2 Warnings and Alarms).
The output data needs to be read from the device and is
therefore not immediately available.
DD_ReadSabWarning_SAB
SAB_REF Sab
BOOL Enable
SabWarningID
Illustration 6.89 DD_ReadSabWarning_SAB
Description
Reference to the SAB.
See chapter 6.5.8.1 SAB_REF.
Get the SAB information
continuously while enabled.
The function block has a valid
set of outputs.
The function block is not
finished and new output
values are to be expected.
An error has occurred within
the function block.
Error identification and
instance identifier.
See chapter 6.5.2.3 Error
Indication.
The value of the SAB error.
Available in the list of
constants: SabErrorCodes.
Valid BOOL
Busy BOOL
Error BOOL
ErrorInfo DD_ERROR_ISD51x
WORD
