SAB Parameter Description
Attribute
LCP parameter number
Access
PDO mapping
Unit
Table 8.11 Object 0x2008: ISD Power Consumption

8.7 Object 0x2009: Fan Speed Power Card

This object shows the speed of the fan on the power card
as a percentage value (0–100%).
Attribute
Index
Description
Object code
Data type
Unit
Sub-index
LCP parameter number
Access
Value range
PDO mapping
Table 8.12 Object 0x2009: Fan Speed Power Card

8.8 Object 0x200D: Relay 1 Control

This object configures the function of relay 1 with the on
and off delay times. The valid configuration values are
detailed in Table 3.2 in chapter 3.2.1 Relay Outputs.
Attribute Value
Index 0x200D
Description Relay 1 Config
Object code Record
Sub-index 0x00
Description Number of entries
Access Read only
PDO mapping No
Value range 0x03
Default value 0x03
Sub-index 0x01
LCP parameter number 05-40
Description Relay 1 Config
Access Read/write
PDO mapping No
Object code Var
Data type UNSIGNED16
Value range See Table 3.2 in chapter 3.2.1 Relay
Outputs.
Default value 0
MG36D102
Programming Guide
Value
16-10
Read only
Yes
Watt
Value
0x2009
Fan speed power card
Var
UNSIGNED16
%
0x00
51-61
Read only
0–100
Yes
Danfoss A/S © 01/2017 All rights reserved.
Attribute Value
Sub-index 0x02
LCP parameter number 05-41
Description Relay 1 on delay
Access Read/write
PDO mapping No
Object code Var
Data type UNSIGNED16
Unit Seconds
Value range 0–600
Default value 0
Sub-index 0x03
LCP parameter number 05-42
Description Relay 1 off delay
Access Read/write
PDO mapping No
Object code Var
Data type UNSIGNED16
Unit Seconds
Value range 0–600
Default value 0
Table 8.13 Object 0x200D: Relay 1 Control

8.9 Object 0x200E: Relay 2 Control

This object configures the function of relay 2 with the on
and off delay times. The valid configuration values are
detailed in Table 3.2 in chapter 3.2.1 Relay Outputs.
Attribute Value
Index 0x200E
Description Relay 2 Config
Object code Record
Sub-index 0x00
Description Number of entries
Access Read only
PDO mapping No
Value range 0x03
Default value 0x03
Sub-index 0x01
LCP parameter number 05-40
Description Relay 2 Config
Access Read/write
PDO mapping No
Object code Var
Data type UNSIGNED16
Value range See Table 3.2 in chapter 3.2.1 Relay
Outputs.
Default value 0
Sub-index 0x02
LCP parameter number 05-41
8 8
