4.5.2 SAB-specific LCP Parameters
Parameter number
00-20
00-21
00-22
00-23
00-24
4 4
50-17
50-18
50-81
51-64
51-65
54-10
54-11
54-13
Table 4.12 SAB-specific LCP Parameters
108
®
VLT Integrated Servo Drive ISD
Name Unit
Display line 1.1 small
Display line 1.2 small
Display line 1.3 small
Display line 2 large
Display line 3 large
U Control
AUX
UDC Control
Position guide value Degrees (°)
reference
AUX line 1 user limit
AUX line 2 user limit
Epl id assignment line
Drive index
Epl id assignment start
Danfoss A/S © 01/2017 All rights reserved.
®
510 System
Description
– Select a variable for display in line 1, left position.
– Select a variable for display in line 1, middle position.
– Select a variable for display in line 1, right position.
– Select a variable for display in line 2.
– Select a variable for display in line 3.
– Enables or disables AUX line voltage.
– Enables or disables UDC.
Scaled position guide value reference (0–360°).
A Sets a user limit for the current on auxiliary line 1. The
current limit can be set in steps of 0.1 A. The value 0 disables
the user current limitation. A warning is set when 90% of the
user current limit is exceeded. Once 100% of the user current
limit is exceeded, the line is switched off and the SAB enters
an error state.
A Sets a user limit for the current on auxiliary line 2. The
current limit can be set in steps of 0.1 A. The value 0 disables
the user current limitation. A warning is set when 90% of the
user current limit is exceeded. Once 100% of the user current
limit is exceeded, the line is switched off and the SAB enters
an error state.
– Selects the SAB line number for the ID assignment.
– Selects the index of the device in the selected line (1–32).
– Starts the manual ID assignment.
