Local Control Panel (LCP) O...
▲ ▼
The [ ] and [ ] keys can be used to toggle between the
values shown in Readout 2 on Double-line readout or
Single-line readout.
Double-line readout
This readout state is a default mode after start-up or initial-
ization. Use the [Info] key to obtain information about the
measurement links to the shown operating variables (1.1,
1.2, 1.3, 2, and 3). See the operating variables shown in
Illustration 4.4.
2
1
1 Readout 1.1
2 Readout 1.2
3 Readout 1.3
4 Readout 2
5 Readout 3
Illustration 4.4 Double-line Readout
Single-line readout
Use the [Info] key to obtain information about the
measurement links to the shown operating variables (1.1,
1.2, 1.3, and 2). See the operating variables shown in
Illustration 4.5. The dynamic data (readout parameters) on
the Status screen is updated 3 times per second.
MG36D102
Programming Guide
1
1
3
2
3
4
4
Illustration 4.5 Single-line Readout
5
4.3.3.1 Default Readouts for ISD 510 Servo
The following parameters are the default readout configu-
ration:
Operating variable
1.1
1.2
1.3
2
3
Table 4.7 Default Readouts for ISD 510 Servo Drive
The readout configuration can be changed and is retained
after a power cycle.
4.3.3.2 Default Readouts for SAB
The following parameters are the default readout configu-
ration:
Operating
variable
1.1
1.2
1.3
2
3
Table 4.8 Default Readouts for SAB
The readout configuration can be changed and is retained
after a power cycle.
Danfoss A/S © 01/2017 All rights reserved.
2
Readout 1.1
Readout 1.2
Readout 1.3
Readout 2
Drive
Name
Torque
Temperature module
Drive position
Speed
Current actual value
Name
AUX line voltage
Temperature power card [16-31]
Actual UDC (current)
ISD power consumption [16-10]
Actual UDC (voltage)
3
4
4
Parameter number
[16-16]
[16-34]
[16-20]
[16-17]
[16-14]
Parameter number
[50-61]
[50-73]
[16-30]
