7.13.6 Parameter 52-45 to 52-48: Additional Homing objects (0x2040)

This object provides additional parameters for the configuration of the homing mode.
Sub-index 01: Homing blocking window velocity
The servo drive assumes that it is blocked when the actual speed falls below the limit that is given in this object, for at least
the time that is given in the Homing blocking window time object. The value is given in user-defined velocity units.
Sub-index 02: Homing blocking window time
This object is used for block detection. The time is given in milliseconds. A value of 0 means immediately.
Sub-index 03: Homing limit distance
This object indicates the maximal distance in which the homing procedure has to be finished. Otherwise, the home
procedure is aborted with an error. The value is given in user-defined position units. A value of 0 disables the limitation.
Sub-index 04: Homing deceleration
This object indicates the configured deceleration to be used during homing procedure. The value is given in user-defined
acceleration units.
