Local Control Panel (LCP) O...
to enable faster changes for larger values. This function
▼
also applies to the [ ] key.
4.4.14 Left [ ] and Right [
◀
When editing a parameter, use the [
cursor 1 digit to the left, and the [
4.5 LCP-specific Parameters
LCP-specific parameters are defined for both the ISD 510 Servo Drive LCP (see chapter 4.5.1 ISD 510 Servo Drive-specific LCP
Parameters) and for the SAB LCP (see chapter 4.5.2 SAB-specific LCP Parameters).
4.5.1 ISD 510 Servo Drive-specific LCP Parameters
Parameter number Name
00-20 Display line 1.1 small
00-21 Display line 1.2 small
00-22 Display line 1.3 small
00-23 Display line 2 large
00-24 Display line 3 large
00-33 Unit for position
readout
00-34 Unit for velocity
readout
00-35 Unit for acceleration
readout
52-02 Hand On mode
52-03 Hand On state
52-11 Positioning type
52-63 Start Inertia
Measurement
52-64 Inertia Measurement
Result
52-70 Jog Mode Control
52-71 Jog speed
Table 4.11 ISD 510 Servo Drive-specific LCP Parameters
MG36D102
Programming Guide
] Keys
▶
◀
] key to move the
▶
] key to move the
Unit
–
–
–
–
–
–
–
–
–
–
–
–
kg m²
–
User units, as defined in
parameter group 00-3*.
Danfoss A/S © 01/2017 All rights reserved.
cursor 1 digit to the right. Both keys have wrap-around
navigation: When the cursor is at the 1
▶
right), pressing the [ ] key moves it to the last digit (on
the far left). This function also applies to the [
◀
When the [ ] key is pressed while navigating the menu
system, the menu screen moves to the previous subgroup
or group. This function also applies to the [
Description
Select a variable for display in line 1, left position.
Select a variable for display in line 1, middle position.
Select a variable for display in line 3, right position.
Select a variable for display in line 2.
Select a variable for display in line 3.
Selects the desired unit for position readout.
Selects the desired unit for velocity readout.
Selects the desired unit for acceleration readout.
Gets or sets the Hand On mode of operation: Position,
Velocity, Jog, or Inertia measurement.
Sets the Hand On state: enabled or disabled.
Gets or sets the positioning type (absolute or relative) when
running in Hand On mode for positioning.
Starts the inertia measurement procedure.
Shows the inertia measurement result.
Enables or disables Jog in Hand On mode.
Contains the commanded jog speed in user units (factor
group has been applied).
st
digit (on the far
◀
] key.
▶
] key.
