Programming
Variable
name
Error
ErrorInfo
AbortCode
Table 6.23 MC_WriteParameter_ISD51x
6 6
6.5.4.22 DD_WriteParameter_ISD51x
This function block asynchronously writes general objects
to the object dictionary of the axis. For the index and sub-
index of the parameters, see chapter 7 Servo Drive
Parameter Description.
The data is written to the device asynchronously and is
therefore not immediately available in the axis.
AXIS_REF_-
ISD51x
BOOL
UINT
USINT
USINT
UDINT
Illustration 6.46 DD_WriteParameter_ISD51x
190
Data Default Description
type value
BOOL An error has occurred
within the function block.
DD_ERROR_ISD51x Error identification and
instance identifier.
See chapter 6.5.2.3 Error
Indication.
DWORD SDO abort code if there is
an error. Available in the
list of constants:
SdoAbortCodes.
DD_WriteParameter_ISD51x
Axis
Execute Done
Index Busy
Subindex Error
Length ErrorInfo
pBu er AbortCode
