Programming
DD_ReadParameter_SAB
SAB_REF Sab
BOOL Enable
UINT Index
USINT Subindex
UDINT pBu er
UDINT Bu erSize
Illustration 6.95 DD_ReadParameter_SAB
Variable Data Default
name type value
VAR_IN_OUT
Sab SAB_REF
VAR_INPUT
Enable BOOL FALSE
Index UINT 0
Subindex USINT 0
pBuffer UDINT 0
BufferSize UDINT 0
VAR_OUTPUT
Valid BOOL
Busy BOOL
Error BOOL
ErrorInfo DD_ERROR_ISD51x
AbortCode DWORD
DataLength UDINT
Table 6.81 DD_ReadParameter_SAB
MG36D102
Programming Guide
Valid BOOL
Busy BOOL
Error BOOL
ErrorInfo DD_ERROR_ISD51x
AbortCode DWORD
DataLength UDINT
Description
Reference to the SAB.
See chapter 6.5.8.1 SAB_REF.
Get the value of the
parameter continuously while
enabled
Index of the object to be read.
Sub-index of the object to be
read.
Pointer to a buffer where the
read data will be placed (use
ADR() function).
Maximum size of the read
data (size of the provided
buffer given in byte; use
SIZEOF() function)
The function block has a valid
output.
The function block is not
finished and new output
values are to be expected.
An error has occurred within
the function block.
Error identification and
instance identifier.
See chapter 6.5.2.3 Error
Indication.
SDO abort code if there is an
error. Available in the list of
constants: SdoAbortCodes.
Length of the read data [Byte].
Danfoss A/S © 01/2017 All rights reserved.

6.5.8.13 DD_WriteParameter4_SAB

This function block asynchronously writes general objects
of up to 4 bytes to the object dictionary of the SAB. For
the index and the sub-index of the parameters, see
chapter 8 SAB Parameter Description.
The data needs to be written to the device asynchronously
and is therefore not available in the SAB immediately.
DD_WriteParameter4_SAB
SAB_REF Sab
BOOL Execute
UINT Index
USINT Subindex
USINT Length
DWORD Value
Illustration 6.96 DD_WriteParameter4_SAB
Variable Data Default
name type value
VAR_IN_OUT
Sab SAB_REF
VAR_INPUT
Execute BOOL FALSE
Index UINT 0
Subindex USINT 0
Length USINT 0
Value DWORD 0
VAR_OUTPUT
Done BOOL
Busy BOOL
Error BOOL
ErrorInfo DD_ERROR_ISD51x
AbortCode DWORD
Table 6.82 DD_WriteParameter4_SAB
Done BOOL
Busy BOOL
Error BOOL
ErrorInfo DD_ERROR_ISD51x
AbortCode DWORD
Description
Reference to the SAB.
See chapter 6.5.8.1 SAB_REF.
Write the value of the
parameter at rising edge.
Index of the object to be
written.
Sub-index of the object to be
written.
Length of the data to be
written [Byte].
New value of the specified
parameter.
The value has been
successfully written to the
device.
The function block is not
finished and new output
values are to be expected.
An error has occurred within
the function block.
Error identification and
instance identifier.
See chapter 6.5.2.3 Error
Indication.
SDO abort code if there is an
error. Available in the list of
constants: SdoAbortCodes.
227
