Danfoss VLT Series Programming Manual page 330

Servo Drive Parameter Descr...
Attribute
Sub-index
Description
Access
Data type
PDO mapping
Value range
Default value
Sub-index
Description
Access
Data type
PDO mapping
Value range
Default value
7 7
Sub-index
Description
Access
Data type
PDO mapping
Value range
Default value
Sub-index
Description
Access
Data type
PDO mapping
Value range
Default value
Sub-index
Description
Access
Data type
PDO mapping
Value range
Default value
Sub-index
Description
Access
Data type
PDO mapping
Value range
Default value
Sub-index
Description
Access
Data type
PDO mapping
Value range
328
®
VLT Integrated Servo Drive ISD
Value
0x03
Trace sample count
Read/write
UNSIGNED16
No
UNSIGNED16
–
0x04
Trace subsampling
Read/write
UNSIGNED16
No
UNSIGNED16
–
0x05
Trace pre-trigger count
Read/write
UNSIGNED16
No
UNSIGNED16
–
0x06
Trace trigger variable ID
Read/write
UNSIGNED32
No
See Table 7.204.
–
0x07
Trigger level
Read/write
FLOAT
No
FLOAT
–
0x08
Trace buffer size
Read only
UNSIGNED16
No
UNSIGNED16
–
0x09
Trace info flags
Read only
UNSIGNED32
No
UNSIGNED32
