Enterasys SecureStack C2 Configuration Manual page 133

Syntax
set lldp port tx-tlv {[all] | [port-desc] [sys-name] [sys-desc] [sys-cap] [mgmt-
addr] [vlan-id] [stp] [lacp] [gvrp] [mac-phy] [poe] [link-aggr] [max-frame] [med-
cap] [med-loc] [med-poe]} port-string
Parameters
all
port‐desc
sys‐name
sys‐desc
sys‐cap
mgmt‐addr
vlan‐id
stp
lacp
gvrp
mac‐phy
poe
link‐aggr
max‐frame
med‐cap
med‐loc
Adds all optional TLVs to transmitted LLDPDUs.
Port Description optional basic LLDP TLV. Value sent is ifDescr object
defined in RFC 2863.
System Name optional basic LLDP TLV. Value sent is the
administratively assigned name for the system.
System Description optional basic LLDP TLV. Value sent is sysDescr
object defined in RFC 3418.
System Capabilities optional basic LLDP TLV. For a network
connectivity device, value sent can be bridge and/or router.
Management Address optional basic LLDP TLV. Value sent is IPv4
address of host interface.
Port VLAN ID IEEE 802.1 Extensions TLV. Value sent is port VLAN
ID (PVID).
Spanning Tree information defined by Protocol Identity IEEE 802.1
Extensions TLV. If STP is enabled on the port, value sent includes
version of protocol being used.
LACP information defined by Protocol Identity IEEE 802.1
Extensions TLV. If LACP is enabled on the port, value sent includes
version of protocol being used.
GVRP information defined by Protocol Identity IEEE 802.1
Extensions TLV. If LACP is enabled on the port, value sent includes
version of protocol being used.
MAC‐PHY Configuration/Status IEEE 802.3 Extensions TLV. Value
sent includes the operational MAU type, duplex, and speed of the
port.
Power via MDI IEEE 802.3 Extensions TLV. Values sent include
whether pair selection can be controlled on port, and the power class
supplied by the port. Only valid for PoE‐enabled ports.
Link Aggregation IEEE 802.3 Extensions TLV. Values sent indicate
whether the link associated with this port can be aggregated,
whether it is currently aggregated, and if aggregated, the aggregated
port identifier.
Maximum Frame Size IEEE 802.3 Extensions TLV. Value sent
indicates maximum frame size of the port's MAC and PHY.
LLDP‐MED Capabilities TLV.Value sent indicates the capabilities
(whether the device supports location information, extended power
via MDI) and Device Type (network connectivity device) of the
sending device.
LLDP‐MED Location Identification TLV. Value sent is the ECS ELIN
value configured on the port. See the set lldp port location‐info
command for more information.
set lldp port tx-tlv
SecureStack C2 Configuration Guide 4-27
