Configuring VRRP

Parameters
vlan vlan‐id
Defaults
If vlan vlan‐id is not specified, IRDP information for all interfaces will be displayed.
Mode
Interface configuration: C2
Example
This example shows how to display IRDP information for the VLAN 1 interface:
C2(su)->router(Config)#interface vlan 1
C2(su)->router(Config-if(vlan 1))#show ip irdp vlan 1
Interface vlan 1 has router discovery enabled
Advertisements will occur between 450 and 600 seconds
Advertisements are sent with broadcasts
Advertisements are valid for 1800 seconds
Default preference will be 0
Configuring VRRP
VRRP is an advanced routing feature that must be enabled with a license key. If you have purchased an
advanced license key, and have enabled routing on the device, you must activate your license as described
in "Activating Licensed
purchase an advanced routing license, contact Enterasys Networks Sales.

Purpose

To enable and configure the Virtual Router Redundancy Protocol (VRRP). This protocol
eliminates the single point of failure inherent in the static default routed environment by
transferring the responsibility from one router to another if the original router goes down. VRRP‐
enabled routers decide who will become master and who will become backup in the event the
master fails.

Commands

For information about...
router vrrp
create
address
priority
advertise-interval
17-38 IPv4 Routing Protocol Configuration
(Optional) Displays IRDP information for a specific VLAN. This VLAN
must be configured for IP routing as described in "Pre‐Routing
Configuration Tasks" on page 15‐1.
(su)‐>router(Config‐if(Vlan 1))#
* Advanced License Required *
Features" on page 15-3 in order to enable the VRRP command set. If you wish to
Refer to page...
17-39
17-39
17-40
17-41
17-42
