Table 16-2 show ip arp Output Details
Output
Protocol
Address
Age (min)
Hardware Addr
Type
Interface

arp

Use this command to add or remove permanent (static) ARP table entries. Up to 1,000 static ARP
entries are supported per SecureStack C2 system. A multicast MAC address can be used in a static
ARP entry. The no form of this command removes the specified permanent ARP entry:
Syntax
arp ip-address mac-address
no arp ip-address
Parameters
ip‐address
mac‐address
Defaults
None.
Mode
Global configuration: C2(su)‐>router(Config)#
Usage
The IP address specified for the static ARP entry must fall within one of the subnets or networks
defined on the routed interfaces of the system ( or stack, if applicable). The system can then match
the IP address of the static ARP entry with the appropriate routed interface and associate it with
the correct VLAN.
Example
This example shows how to add a permanent ARP entry for the IP address 130.2.3.1 and MAC
address 0003.4712.7a99:
C2(su)->router(Config)#arp 130.2.3.1 0003.4712.7a99

ip proxy-arp

Use this command to enable proxy ARP on an interface. The no form of this command disables
proxy ARP.
What It Displays...
ARP entry's type of network address.
Network address mapped to the entry's MAC address.
Interval (in minutes) since the entry was entered in the table.
MAC address mapped to the entry's network address.
Encapsulation type used for the entry's network address.
Interface (VLAN or loopback) through which the entry was learned.
Specifies the IP address of a device on the network. Valid values are IP
addresses in dotted decimal notation.
Specifies the 48‐bit hardware address corresponding to the ip‐address
expressed in hexadecimal notation.
SecureStack C2 Configuration Guide 16-9
