set rmon capture

Parameters
index
nodata
Defaults
If no options are specified, all buffer control entries and associated captured packets will be
displayed.
Mode
Switch command, read‐only.
Example
This example shows how to display RMON capture entries and associated buffer entries:
C2(rw)->show rmon capture
Buf.control= 28062
----------------------------------------------------------
FullStatus
Captured packets
Download size
Max Octet Requested 50000
Start time
Owner
captureEntry= 1
--------------------------------------------
Pkt ID
Pkt Length
Data:
00 00 5e 00 01 01 00 01 f4 00 7d ce 08 00 45 00
00 4b b4 b9 00 00 40 11 32 5c 0a 15 43 05 86 8d
bf e5 00 a1 0e 2b 00 37 cf ca 30 2d 02 01 00 04
06 70 75 62 6c 69 63 a2 20 02 02 0c 92 02 01 00
02 01 00 30 14 30 12 06 0d 2b 06 01 02 01 10 07
01 01 0b 81 fd 1c 02 01 01 00 11 0b 00
set rmon capture
Use this command to configure an RMON capture entry.
Syntax
set rmon capture index {channel [action {lock}] [slice slice] [loadsize loadsize]
[offset offset] [asksize asksize] [owner owner]}
Parameters
index
channel
13-20 RMON Configuration
(Optional) Displays the specified buffer control entry and all captured
packets associated with that entry.
(Optional) Displays only the buffer control entry specified by index.
Channel= 38283
avail FullAction
251 Capture slice
100 Download offset
Max Octet Granted
1 days 0 hours 51 minutes 15 seconds
monitor
Buff.control= 28062
9 Pkt time
93 Pkt status
Specifies a buffer control entry.
Specifies the channel to which this capture entry will be applied.
EntryStatus= valid
lock
1518
0
50000
1 days 0 hours 51 minutes 15 seconds
0
