CDM-Qx Satellite Modem
Summary of Specifications
A.7

Miscellaneous

Front panel
Loopbacks
Fault relays
M&C Interface
M&C Software
AC Consumption
AC Operating Voltage
DC Operating Voltage
Temperature:
Operating
Storage
Dimensions
Weight
CE Mark
FCC
Tactile keypad, 6 keys (Up/Down, Left/Right, Enter/Clear)
Vacuum Fluorescent Display (blue) - 2 lines of 40 characters
Internal IF loopback, RF loopback, digital loopback, and inward/outward loopback
Hardware fault, RX and TX Traffic Alarms
EIA-232 and EIA-485 (addressable multidrop, 2-wire or 4-wire), 10/100 BaseT Ethernet
SATMAC software for control of local and distant units
(Depends on configuration)
120 watts (maximum) for 70/140,
250 watts (maximum for L-Band
100 to 240 VAC, +6%/-10% - autosensing
(total absolute max. range is 90 to 254 VAC)
36 to 72 VDC, 6.25 amps
o o
0 to 50 C (32 to 122 F)
o o
-25 to 85 C (-13 to 185 F)
1.75H x 19W x 19D inches (4.4H x 48W x 48D cm)
< 20 lbs (7.0 kg) approx (depends on configuration)
EMC Safety
Part 15
