Cisco Small Business 300 1.1 Series Administration Manual page 71

System Management Commands
78-20269-01 Command Line Interface Reference Guide
User Guidelines
Press Esc to stop pinging. Following are sample results of the ping command:
•
Destination does not respond—If the host does not respond, a "no answer
from host" appears within 10 seconds.
•
Destination unreachable—The gateway for this destination indicates that
the destination is unreachable.
•
Network or host unreachable—The switch found no corresponding entry in
the route table.
The format of an IPv6Z address is: <
•
interface-name =
<physical-port-name> | 0
•
integer = < decimal-number> | <integer><decimal-number
•
decimal-number =
•
physical-port-name = Designated port number, for example gi 1 . If the
physical-port-name = 0, then it is not defined and the default interface is
used
.
When using the ping ipv6 command to check network connectivity of a directly
attached host using its link local address, the egress interface may be specified in
the IPv6Z format. If the egress interface is not specified, the default interface is
selected.
When using the ping ipv6 command with a Multicast address, the information
displayed is taken from all received echo responses.
Examples
Example 1- Ping an IP address.
Console> ping ip 10.1.1.1
Pinging 10.1.1.1 with 64 bytes of data:
64 bytes from 10.1.1.1: icmp_seq=0. time=11 ms
64 bytes from 10.1.1.1: icmp_seq=1. time=8 ms
64 bytes from 10.1.1.1: icmp_seq=2. time=8 ms
64 bytes from 10.1.1.1: icmp_seq=3. time=7 ms
ipv6-link-local-address>%<interface-name
vlan<integer> | po<integer> | isatap<integer> |
0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9
