17.1.7 Type Identification
®
The ID number of the RTC
the board's factory-equipped jumper configuration
(JP1-JP8). The jumper configuration is additionally
encoded in a three-digit type code scheme:
Digit 1 =0: Jumper JP1 open (no signal)
=1: Jumper JP1 in position 1-2 (5 V)
=2: Jumper JP1 in position 2-3 (3.3 V)
Digit 2 =0: Jumper JP2-JP4 open (no signal)
(relates =1: Jumper JP2 closed (+5 V)
to pin =2: Jumper JP3 closed (DATA7)
B40) =3: Jumper JP4 closed (GND)
Digit 3 =0: Jumper JP5-JP8 open (no signal)
(relates =1: Jumper JP5 closed (+5 V)
to pin =2: Jumper JP6 closed (DATA7)
B42) =3: Jumper JP7 closed (GND)
=4: Jumper JP8 closed (LATCH)
Examples:
• "Type 000": jumpers JP1-JP8 open
• "Type 124": JP1 in position1-2 (5 V signal level),
JP3 closed (DATA7 at pin B40),
JP8 closed (LATCH an pin B42)
®
RTC 5 PC Interface Board
Rev. 1.9 e
®
17 Appendix C: The RTC 5 PCIe/104 Board
5 PCIe/104 board reveals
17.1.8 Unpacking Instructions and
Typical Package Contents
 Carefully remove the RTC
the package.
 Keep the packaging, including the antistatic bag
®
the RTC 5 PCIe/104 board is delivered in, so that
in case of repair the board can be properly
repackaged and returned to SCANLAB.
 Also remove all other articles from the package.
Check that all parts have been delivered. Refer to
the corresponding packaging list.
The package typically includes an RTC
board and a data CD (containing the corre-
sponding software (see below) and this manual).
Some product versions may also supply
additional components such as data cables or
converters (see "Optional Accessories", page
Delivered Software
The delivered software package is identical to the
®
RTC 5 software package (see
software drivers for Microsoft's WINDOWS 8,
WINDOWS 7, WINDOWS Vista and WINDOWS XP
(SP2 or higher) and WINDOWS XP Embedded (SP2 or
higher) (32-bit or 64-bit) operating systems,
correction, DLL and program files, as well as utility
files for C, C++ and C#.
17.1.9 Optional Accessories
®
In addition to the RTC 5 PCIe/104 board and its
software package, the following accessories – as with
®
the RTC 5 PC interface board – can be obtained from
SCANLAB (only hardware extensions from SCANLAB
should be used in combination with the
®
RTC 5 PCIe/104 board):
• XY2-100 converter (see
• Data cables (see page 29).
• Laser adapter (see page
• Slot cover with a 15-pin D-SUB connector for
using the inputs and signals of the LASER
connector (see page 580)
17.1.10 Supplementary Software
®
For customizing RTC correction files on the basis of
test measurements, SCANLAB offers the correXion5
program and its associated manual (also see
page 121).
®
5 PCIe/104 board from
®
5 PCIe/104
600).
page 23). It contains
page 29).
29).
