Undelayed if_not_cond
Short
List Command
Function Conditional command execution: This command immediately executes the directly
following list command, if the current IOvalue at the EXTENSION 1 connector's 16-bit
digital input port does not meet the following condition:
((IOvalue AND Mask1) = Mask1) AND (((not IOvalue) AND Mask0) = Mask0)
(i.e. if the bits specified in Mask1 are not 1 or the bits specified in Mask0 are not 0).
Otherwise, the next list command is skipped over.
Call
if_not_cond( Mask1, Mask0 )
Parameters
Mask1,
Mask0
Comments • Also see
® ®
RTC 4 RTC 5 new command
References if_cond, if_pin_cond,
Undelayed if_not_fly_x_overflow
Short
List Command
Function Conditional command execution for Processing-on-the-fly applications: This command
immediately executes the directly subsequent list command if the condition in accordance
with Mode for the X axis was not fulfilled. Otherwise, the next list command is skipped over.
Call
if_not_fly_x_overflow( Mode )
Parameters
Mode
Comments • For command usage, see
• The error bits queried in accordance with Mode (error bit#4 and/or error bit#5) will be
reset.
® ®
RTC 4 RTC 5 new command
Version info Available beginning with version DLL 525, OUT 527
References get_marking_info, set_fly_limits, clear_fly_overflow,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
16-bit masks as unsigned 32-bit values
(only the least significant 16 bits are evaluated)
"Conditional Command Execution", page
if_not_pin_cond
To-be-evaluated condition as a signed 32-bit value:
= 0: Some kind of boundary exceedance occurred
(error bit#4 = 1 or error bit#5 = 1).
> 0: An overflow occurred (error bit#5 = 1).
< 0: An underflow occurred (error bit#4 = 1).
page 190.
213.
if_fly_x_overflow
