Ctrl Command read_status
Function
returns the RTC
Call
Status = read_status()
Result
list status as an unsigned 32-bit value:
Bit #
Bit #0 (LSB)
Bit #1
Bit #2
Bit #3
Bit #4
Bit #5
Bit #6
Bit #7
Bits #8...#31
®
RTC
5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
®
5 list status (see
"List Status", page
Name
Description
LOAD1
= 1:
indicates that the input pointer is currently in "List 1", i.e. that all following
list commands will be stored in "List 1". LOAD1 is set if the input pointer is
set into "List 1" (e.g. via set_start_list_pos). LOAD1 is reset if a
set_end_of_list
set (e.g. via set_start_list_pos).
LOAD2
= 1:
indicates that the input pointer is currently in "List 2", i.e. that all following
list commands will be stored in "List 2". LOAD2 is set if the input pointer is
set into "List 2" (e.g. via set_start_list_pos). LOAD2 is reset if a
set_end_of_list
set (e.g. via set_start_list_pos).
READY1
= 1:
indicates that during the loading procedure a
written to "List 1". READY1 is reset if LOAD1 is newly set (e.g. via
set_start_list_pos).
READY2
= 1:
indicates that during the loading procedure a
written to "List 2". READY2 is reset if LOAD2 is newly set (e.g. via
set_start_list_pos).
BUSY1
= 1:
indicates that "List 1" is executing at the moment (or more precisely: that the
output pointer currently resides in "List 1" after execution of "List 1" or
"List 2" was started). BUSY1 is set via starting execution of "List 1" (e.g. via
execute_list_pos) or via a list change to "List 1" (automatic list change or
jump). BUSY1 is reset if
"List 2" is executed (e.g. list_jump_pos), if "List 2" is started (e.g. via
execute_list_pos) or if
BUSY2
= 1:
indicates that "List 2" is executing at the moment (or more precisely: that the
output pointer currently resides in "List 2" after execution of "List 1" or
"List 2" was started). BUSY2 is set via starting execution of "List 2" (e.g. via
execute_list_pos) or via a list change to "List 2" (automatic list change or
jump). BUSY2 is reset if
"List 1" is executed (e.g. list_jump_pos), if "List 1" is started (e.g. via
execute_list_pos) or if
USED1
= 1:
indicates that a
"List 1". USED1 is reset when LOAD1 is set (e.g. via set_start_list_pos).
USED2
= 1:
indicates that a
"List 2". USED2 is reset when LOAD2 is set (e.g. via set_start_list_pos).
1
72).
command is written to "List 1" (READY1 set) or if LOAD2 is
command is written to "List 2" (READY2 set) or if LOAD1 is
set_end_of_list
set_end_of_list
set_end_of_list
is executed in "List 1", if a jump into
stop_execution
is executed.
set_end_of_list
is executed in "List 2", if a jump into
stop_execution
is executed.
set_end_of_list
command was reached during processing of
set_end_of_list
command was reached during processing of
command was
command was
390
