SL2-100-compliant data transmission
1 DATA IN+
6 DATA IN–
2
7
3
8
4
9 DATA OUT –
5 DATA OUT+
D-SUB
9 pin male
XY2-100-compliant data transmission
1 CLOCK–
14
CLOCK+
2
SYNC–
15 SYNC+
3 CHAN1 –
16 CHAN1+
4 CHAN2 –
17 CHAN2+
5
18
6 STATUS– *
19 STATUS+ *
7
20
8 STATUS1 – *
21 STATUS1+ *
9
22
10
23
11
24
12
25
13
D-SUB
25 pin male
®
* For iDRIVE scan systems (intelliSCAN
STATUS± channel is the status channel of axis 2 (X axis; this channel is then also called STATUS2±) and the STATUS1±
channel is the status channel of axis 1 (Y axis). For other scan systems, the STATUS1± channel is not needed.
Data cable layout and pin assignments
®
RTC 5 PC Interface Board
Rev. 1.9 e
4 Layout and Interfaces
Shielding
Shielding
® ® ®
, intelliSCAN , intelliDRILL , intellicube
de
DATA IN +
DATA IN –
DATA OUT –
DATA OUT+
Ferrit ring
CLOCK –
CLOCK+
SYNC –
SYNC+
CHAN1 –
CHAN1+
CHAN2 –
CHAN2+
STATUS – *
STATUS+ *
STATUS1– *
STATUS1+ *
® ®
, intelliWELD , varioSCAN ), the
de
1
6
2
7
3
8
4
9
5
D-SUB
9 pin male
1
14
2
15
3
16
4
17
5
18
6
19
7
20
8
21
9
22
10
23
11
24
12
25
13
D-SUB
25 pin male
