Undelayed read_io_port_list
Short
List Command
Function writes into the internal IOPort buffer the current state (DIGITAL IN0 ... DIGITAL IN15) of
the EXTENSION 1 connector's 16-bit digital input. At the same time, the current XY set
positions and (relative) time in seconds are stored.
Call
read_io_port_list()
Comments • The read_io_port_list command does not return values. However, the values can be
subsequently queried from the IOPort buffer via the
• The IOPort buffer holds 16 entries and is circularly organized. It always stores the 16
most recent entries and overwrites older entries without warning. The incremental
Index starts after a reset (program start) at Index 0, and after passing 15 will rollover to
0.
• The stored time is the current value of an internal seconds counter that is set to 0 at
program start (load_program_file) or via time_update.
• Also see section
® ®
RTC 4 RTC 5 new command
read_io_port_buffer,
References
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
"16-Bit Digital Input", page
read_io_port
read_io_port_buffer
207.
command.
