Normal set_softstart_level_list
List Command
Function similar to
Call
set_softstart_level_list( Index, Level1, Level2, Level3 )
Parameters See set_softstart_level.
Comments • The set_softstart_level
Index through Index+3. The command must be called separately for each individual
Level1/2/3 value-triple.
• Index must be in the range [0...1023], otherwise the set_softstart_level_list
command will, already during loading, be replaced by a
code RTC5_PARAM_ERROR).
• Softstart won't use level values where the index count exceeds Number (Number is spec-
ified via set_softstart_mode).
• Otherwise this command is identical to the control command
see the comments there).
• If the "freely defined wobbel shape" wobbel mode is activated, then this command will
have no effect; see
® ®
RTC 4 RTC 5 new command
®
In RTC 4 compatibility mode: see
Version info Available as of version DLL 536, OUT 536
References set_softstart_level, set_softstart_mode,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
set_softstart_level (see above), but a list command
command defines three Level values for the pulses number
chapter 8.4 "Wobbel Mode", page
set_softstart_level
list_nop (get_last_error
set_softstart_level
167.
set_softstart_mode_list
return
(also
