Ctrl Command load_list
Parameters
ListNo
Pos
Result Number of the opened list [1 or 2] if successful, otherwise 0
(as an unsigned 32-bit value)
Comments • The load_list command (ListNo = 3) is useful in scenarios such as alternating list
changes, where you want to wait specifically for a list to be processed (see
List Changes", page
tional overwriting of not-yet-executed commands is thereby automatically avoided. To
instead perform unconditional loading, you can use commands such as
set_start_list_pos.
• After a successful check of the list number (BUSY status not set and, if applicable, USED
status set), the load_list command behaves like
there).
• If the load_list command was not successful (return code 0), then no list will be opened
and the input pointer will be set to an invalid position. Then no further list commands
can be input until the input pointer is correctly set (e.g. by repeating the load_list
command with a positive result or via the
the user to react to a return code of 0. The load_list command produces no wait loop
and doesn't block execution of subsequent control commands.
• If ListNo = 0...2 when using the load_list command, then note that a list's BUSY status
can change between opening of the list with load_list and the actual loading of list
commands, e.g. if in the meantime an automatic list change has occurred that was
previously defined via
of a list might occur simultaneously with processing of the same list, the user must
always ensure that the output pointer does not overtake the input pointer.
• In contrast, for ListNo = 3 load_list ensures that a list is actually opened for loading
only directly after processing (and after any successful automatic list changes). Particu-
larly, if no list is BUSY and both lists are USED (e.g. after initialization, after
stop_execution
with the following automatic list change.
® ®
RTC 4 RTC 5 new command
References set_start_list_pos
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
Number of the list in which the input pointer should be set, as an unsigned
32-bit value; permissible values: [0 ... 3]; only the two least significant bits are
evaluated.
=1: "List 1" will be opened if not BUSY (BUSY1 status not set).
=2: "List 2" will be opened if not BUSY (BUSY2 status not set).
=0: The list that is currently not BUSY will be opened. If both lists are not BUSY, then "List 1" will
be opened.
=3: The list that is currently not BUSY but USED (USED status set) will be opened. If both lists are
not BUSY and both are USED, then that list will be opened, which would be executed by a
following automatic list change.
For Mem2 = 0 (see config_list) "List 1" will be opened if not BUSY (ListNo = 0...2) or if not BUSY
but USED (ListNo = 3).
Position of the input pointer (offset relative to the start of the respective list)
as an unsigned 32-bit value; permissible range: [0 ... (2
75) without needing to separately query the list status. Uninten-
auto_change
or after an external list stop), the opened list number is synchronized
set_start_list_pos
set_start_list_pos command etc.). It is up to
or start_loop. In cases such as this, where loading
20
–1)]
"Alternating
(see comments
