Scanlab RTC 5 PC Interface Board Installation And Operation Manual page 452

Ctrl Command set_mcbsp_in
Function activates Processing-on-the-fly correction for compensation of a workpiece or scan system
movement (based on position values transferred to the RTC
the McBSP interface can also be used for inputting other desired signals.
Restriction If the Processing-on-the-fly option is not enabled, then the command terminates the
Processing-on-the-fly process (even though it couldn't have been activated).
Call
set_mcbsp_in( Mode, Scale )
Parameters
Mode
Scale
Comments • You can query the internal memory locations at any time via read_mcbsp.
• For Processing-on-the-fly correction and determination of the scaling factor, see
"Processing-on-the-fly (Optional)", page
• The various Processing-on-the-fly corrections can't be arbitrarily combined (see the
page
• For deactivating Processing-on-the-fly correction, see
• 15 bits per axis (with sign) are effectively available for two-dimensional correction
(Mode = 3), whereby the X value is in the lower 16 bits of the "bit#31 = 0"-coded
McBSP input value and the Y value in the upper 16 bits.
• The McBSP interface can't be simultaneously used for both Processing-on-the-fly appli-
cations and online positioning (see
• The McBSP interface always ignores the first FrameSync signal after a
load_program_file
page
• If Mode > 5, set_mcbsp_in is not executed
RTC5_PARAM_ERROR).
• If an unallowed Scale parameter value is supplied (e.g. Scale = 0), set_mcbsp_in
behaves as with Mode = 0.
® ®
RTC 4 RTC 5 new command
Version info Available beginning with version DLL 531, OUT 532
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
an unsigned 32-bit value, allowed values:
= 0: Processing-on-the-fly correction will be switched off
= 1: compensation of linear movement in the X direction
= 2: compensation of linear movement in the Y direction
= 3: compensation of linear movement in the X and Y directions
= 4: compensation of rotary movement
= 5: Processing-on-the-fly correction will be switched off
• Mode = 0 ... 5: All McBSP input values will be alternatingly copied to
internal memory locations 1 and 2.
• Mode = 1 ... 5 (but not for Mode = 0): McBSP input values coded with
"Bit#31 = 0" will additionally be copied to internal memory location 0 and
those with "Bit#31 = 1" to internal memory location 3.
• Mode = 1 ... 4: Values copied to internal memory location 0 will be applied
for Processing-on-the-fly correction.
scaling factor or rotation resolution as a 64-bit IEEE floating point value:
• Mode = 1 ... 3: scaling factor in (RTC
allowed range: 1/256  |Scale|  16000.0
(if Mode = 3, Scale applies to both axes)
• Mode = 4: number of steps (counts) per revolution;
allowed range: |Scale| > 100.0
178).
or mcbsp_init, so available data will not be transmitted (see
53).
®
5 via the McBSP interface);
®
5)bits/(McBSP)bit;
177.
page 186.
page 166).
(get_last_error return code:
452
