Variable laser_on_list
List Command
Function turns on the "laser active" laser control signals for a specified time interval.
Call
laser_on_list( Period )
Parameter
Period
Comments • As of Version OUT 531, bit #31 of Period is ignored (also see comments and version
info at laser_on_pulses_list).
• The laser control signals for "laser active" operation must first be selected with
set_laser_mode, defined via further commands, and enabled via
enable_laser
• While the laser control signals are turned on, the set position of the scanners is not
changed. The next list command will be executed when the programmed time interval
has passed.
• The currently set LaserOn delay is applied at the beginning of the programmed time
interval: The laser control signals turn on after a LaserOn delay.
– As with other mark commands (e.g. mark_abs), the laser control signals will not
explicitly turn off at the end of the time interval, but instead will only turn off with
a subsequent list command (e.g.
delay is applied.
• The command is useful for marking separate points (see
• Wobbel Mode (see
• For Period = 0 the laser control signals won't turn on; then the laser_on_list command
is a short list command.
® ®
RTC 4 RTC 5 unchanged functionality (except for the extended range of values)
Version info Last change with version DLL 530, OUT 531, RBF 522: changed functionality for
31  Period  (2
2
References laser_on_pulses_list,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
time interval in bits as an unsigned 32-bit value.
1 bit equals 10 µs. Allowed range: 0  Period  (2
before they can be switched on with laser_on_list (see
jump_abs
page 167) will be retained, but will be ignored.
32
–1) (see comments for laser_on_pulses_list).
para_laser_on_pulses_list
31
–1)
set_laser_control
page
or list_nop). The currently set LaserOff
page 96).
or
128).
