Normal mark_serial
List Command
Function marks the current serial number of the serial-number-set most recently selected via
select_serial_set_list
format at the current position. Afterward the serial number is (optionally) automatically
incremented.
Call
mark_serial( Mode, Digits )
Parameters
Mode
Digits
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
(or of serial-number-set 0 after load_program_file) in the selected
Selection of the serial number format and (de)activation of automatic serial
number incrementing as an unsigned 32-bit value.
Mode = 20 · M + 10 · M + M
1 2
(allowed range for M : [0, 1], for M
1
a) Selection of the character set for digit marking
• M = 0: The indexed text string for digits [30...39], as defined via
1
load_text_table or set_text_table_pointer, will be marked.
• M = 1: The indexed characters for digits [0...9], as defined via
1
or set_char_pointer, will be marked. The desired character set can be
selected (previously) with select_char_set.
b) Incrementing of the serial number after marking
• M = 0: The serial number is incremented after marking.
2
• M = 1: The serial number is not incremented after marking.
2
c) Marking of leading zeros
• M = 0: Leading zeros are marked as zeros. Dependent on M
3
sponding indexed text string definition (Index = 30) or the indexed char-
acter definition '0' is used.
• M = 1: Leading zeros are suppressed (left-justified marking).
3
• M = 2: Leading zeros are marked as blank characters (right-justified
3
marking). Dependent on M
tion (Index = 29) or the indexed character definition ' ' is used.
number [0-12] of to-be-marked digits as an unsigned 32-bit value;
allowed range: [0-12]; larger values will be clipped.
3
: [0, 1], for M : [0 ... 2])
2 3
the corresponding indexed text string defini-
1
load_char
the corre-
1
