Ctrl Command set_control_mode
® ®
RTC 4 RTC 5 In contrast to the RTC
the 16-bit digital output port for I/O commands. The RTC
these bits for varioSCAN
these bits (release automatically occurs via load_program_file).
Otherwise: unchanged functionality for the bits that are also used on the RTC
Version info Last change (DLL 528, OUT 530): bit#1
References set_extstartpos, get_counts, set_max_counts, get_startstop_info,
Normal set_control_mode_list
List Command
Function similar to
Call
set_control_mode_list( Mode )
Parameter Mode (as an unsigned 32-bit value)
Comments • The counter for external list starts is not reset by this command.
® ®
RTC 4 RTC 5 unchanged functionality for the bits that are also used on the RTC
Version info Last change (DLL 528, OUT 530): bit#1
References set_control_mode
Ctrl Command set_default_pixel
Function defines the pulse length default value for the default pixel that terminates pixel output
mode.
Call
set_default_pixel( PulseLength )
Parameters
PulseLength
Comments • In pixel output mode, the pixel pulse length at the end of an image line (at the begin-
ning of the default pixel) will get set to the specified default value (see
• When the RTC
is set to 0.
® ®
RTC 4 RTC 5 new command
References set_port_default
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
®
4, bit#8 cannot not be used to lock or unlock the upper 8 bits of
control via move_to. It's not possible to explicitly release
FLEX
set_control_mode (see above), but a list command
default pixel pulse length (as an unsigned 32-bit value).
1 bit equals 1/64 µs. Allowed range: [0 ... (2
®
5 is initialized (via load_program_file), the pulse length default value
®
5 automatically reserves (locks)
®
4
move_to
®
4
32
1)]
–
page 194).
