Ctrl Command get_marking_info
Function returns information about any boundary exceedances during Processing-on-the-fly
correction as well as improper encoder signals;
also returns the error bits of laser-signal auto-suppression.
Call
MarkingInfo = get_marking_info()
Result Error code as an unsigned 32-bit value:
Bit #0 (LSB)
Bit #1
Bit #2
Bit #3
Bit #4
Bit #5
Bit #6
Bit #7
Bit #8
Bit #9
Bit #10
Bit #11
Bit #12
Bit #13
Bit #14
Bit #15
Bit #16
Bit #17
Bit #18
Bit #19
Bit #20
Bit #21
Bit #22
Bit #23
Bit #24
Bit #25
Bit #26
Bit #27
Bit #28
Bit #29
Bit #30
Bit #31
The remaining bits are reserved.
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
= 1: Processing-on-the-fly underflow in X direction (X < –524288)
= 1: Processing-on-the-fly overflow in X direction (X > +524287)
= 1: Processing-on-the-fly underflow in Y direction (Y < –524288)
= 1: Processing-on-the-fly overflow in Y direction (Y > +524287)
= 1: Processing-on-the-fly underflow in X direction (X < Xmin)
= 1: Processing-on-the-fly overflow in X direction (X > Xmax)
= 1: Processing-on-the-fly underflow in Y direction (Y < Ymin)
= 1: Processing-on-the-fly overflow in Y direction (Y > Ymin)
= 1: TriggerError: an enabled external trigger or simulated trigger occurred during execution of a
list
= 1: ActivateFlyError: an error has occurred during activation of Processing-on-the-fly correction
via activate_fly_2d or activate_fly_xy
PosAck error bit of head A's X axis
TempOK error bit of head A's X axis
PowerOK error bit of head A's X axis
PosAck error bit of head A's Y axis
TempOK error bit of head A's Y axis
PowerOK error bit of head A's Y axis
= 1: Signal 1 of encoder input ENCODER X has too-short spacing
= 1: Signal 2 of encoder input ENCODER X has too-short spacing
= 1: Signal 1 of encoder input ENCODER Y has too-short spacing
= 1: Signal 2 of encoder input ENCODER Y has too-short spacing
= 1: Improper signal sequence at encoder input ENCODER X
= 1: Improper signal sequence at encoder input ENCODER Y
= 1: Processing-on-the-fly underflow in Z direction (Z < –32.768)
= 1: Processing-on-the-fly overflow in Z direction (Z > +32.767)
= 1: Processing-on-the-fly underflow in Z direction (Z < Zmin)
= 1: Processing-on-the-fly overflow in Z direction (Z > Zmax)
PosAck error bit of head B's X axis
TempOK error bit of head B's X axis
PowerOK error bit of head B's X axis
PosAck error bit of head B's Y axis
TempOK error bit of head B's Y axis
PowerOK error bit of head B's Y axis
(also see chapter 8.7.7, page 188)
