Control load_jump_table_offset
Command
Notes • For information on command usage, see
page
• For jump mode information, see
• Format requirements for placing the table with jump delay data points into the text file
are described in the section
page
appropriate values for the complete jump length range.
• The command load_jump_table_offset overwrites any previously loaded jump delay
tables for jump mode.
• If Name = filename, then the table number No will be loaded. The other parameters
aren't used.
• If Name = 0, then the jump delay table for head No will be automatically determined and
loaded (if jump mode has been previously enabled and activated successfully via
set_jump_mode
MaxDelay and ListPos will be used (see
Table", page
• Jump mode takes effect upon the next 2D jump only if it was activated and enabled via
set_jump_mode
• The command load_jump_table_offset will not execute
RTC5_BUSY) if the board's BUSY status is currently set (list is being processed or was
paused via pause_list) or if the board's INTERNAL BUSY status is set. In contrast, the
command will execute if a list was paused via
• During the command's execution, external starts will be suppressed.
• Before loading a table, load_jump_table_offset performs a DSP memory check that
produces error code 4 in case of error.
® ®
RTC 4 RTC 5 new command
There is no RTC
Version info Available beginning with version DLL 526
Reference load_jump_table, set_jump_mode, set_jump_mode_list, get_jump_table,
set_jump_table
Ctrl Command load_list
Function opens the list buffer for writing with list commands and sets the input pointer to the
specified (relative) position within the desired list ("List 1" or "List 2"), but only if the list
is not currently being processed (BUSY status not set) or has already been processed (USED
status set). In case of success, the next list command will be stored at this address and all
further commands at subsequent addresses in the selected list.
Call
NoOfOpenedList = load_list( ListNo, Pos )
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
157.
"Notes on Loading Determined Jump Delay Values" on
158. When loading the table, the RTC
(Flag = 1)). Here, the parameters PosAck, Offset, MinDelay,
159).
or activated via set_jump_mode_list.
®
4 compatibility mode for this command.
"Jump-Length-Dependent Jump Delays",
page 156.
®
5 uses linear interpolation to establish
"Automatic Determination of the Jump Delay
(get_last_error
set_wait (PAUSED status set).
return code:
