Ctrl Command set_laser_mode
Function selects the laser control mode of the RTC
Call
set_laser_mode( Mode )
Parameter
Mode
Comments • The available laser signals depend on the selected laser control mode. Refer to
chapter 7.4 "Laser Control", page 128
• The command should be used only once at the program start.
Also see
® ®
RTC 4 RTC 5 YAG mode 5 and laser mode 6 were introduced for the RTC
Otherwise unchanged functionality
References set_laser_control, set_laser_pulses_ctrl, set_laser_pulses, set_laser_timing,
set_firstpulse_killer, set_firstpulse_killer_list, set_standby, set_standby_list,
set_qswitch_delay,
Ctrl Command set_laser_off_default
Function defines the default output value for the ANALOG OUT1 and ANALOG OUT2 ports, as well
as the RTC
Call
set_laser_off_default( AnalogOut1, AnalogOut2, DigitalOut )
Parameters
AnalogOut1,
AnalogOut2
DigitalOut
Comments • The default values can also be defined via the command
comments there).
® ®
RTC 4 RTC 5 new command
®
In RTC 4 compatibility mode, the RTC
and AnalogOut2 by 4 (the RTC
References set_port_default
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
as an unsigned 32-bit value
= 0: CO mode
2
= 1: YAG mode 1
= 2: YAG mode 2
= 3: YAG mode 3
= 4: laser mode 4
= 5: YAG mode 5
= 6: laser mode 6
"Start of Operation", page
set_qswitch_delay_list
®
5's 8-bit digital output port.
12-bit values for analog output ports ANALOG OUT1 and ANALOG OUT2
(also see page 47) as unsigned 32-bit values. Higher bits are ignored
(exception: AnalogOut1/2 = "–1", see comments for set_port_default).
8-bit value for the 8-bit digital output port (also see
unsigned 32-bit value. Higher bits are ignored (exception: DigitalOut =
"–1", see comments for set_port_default).
®
4's analog outputs only handled 10-bit values).
®
5
for a detailed description.
65.
®
5.
set_port_default
®
5 multiplies the specified values for AnalogOut1
page 50) as an
(also see
