List Multi- set_delay_mode_list
Command
Function identical with
Call
set_set_delay_mode_list( VarPoly, DirectMove3D, EdgeLevel, MinJumpDelay,
JumpLengthLimit )
Parameters See set_delay_mode.
Comments • See set_delay_mode.
• The command requires two list buffer positions and executes as two undelayed short
list commands.
• Any still-pending delayed short list command will execute first.
® ®
RTC 4 RTC 5 new command,
®
RTC 4 compatibility mode: see
Version info Available beginning with version DLL 536, OUT 536
References set_delay_mode
Ctrl Command set_dsp_mode
Function sets a DSP mode for short-command count.
Call
initial_dsp_mode = set_dsp_mode( Mode )
Parameter
Mode
Result DSP mode for which the board was set during initialization (as an unsigned 32-bit value)
Comments • This command is only needed when multiple RTC
are to be operated synchronously in a master/slave chain (see
if matching of short list counts isn't to be performed via sync_slaves.
• Even if another mode was already set via set_dsp_mode, the set_dsp_mode command
always returns the DSP mode that the board was set to during initialization. This return
value (initial_dsp_mode) is identical to Byte #2 of
number).
• No mode can be set that is larger than initial_dsp_mode (if necessary, Mode will be
clipped to initial_dsp_mode). Thus, faster boards can only be matched to slower
boards, not the other way around.
® ®
RTC 4 RTC 5 new command
Version info • Available beginning with version DLL 523, OUT 524
References sync_slaves,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
set_delay_mode (see above), but a list command
set_delay_mode
desired DSP mode as an unsigned 32-bit value
get_rtc_version
®
5 boards with differing DSP versions
page 84), and then only
get_rtc_version (DSP version
