Undelayed sub_call_abs_cond
Short
List Command
Function Conditional call (AbsCall) of an indexed subroutine: This command executes the command
sub_call_abs( Index ), if the current IOvalue at the EXTENSION 1 connector's 16-bit
digital input port meets the following condition:
((IOvalue AND Mask1) = Mask1) AND (((not IOvalue) AND Mask0) = Mask0)
(i.e. if the bits specified in Mask1 are 1 and the bits specified in Mask0 are 0). Otherwise, the
directly following list command will be immediately executed.
Call
sub_call_abs_cond( Mask1, Mask0, Index )
Parameters
Mask1,
Mask0
Index
Comments • See sub_call_abs.
• Also see
® ®
RTC 4 RTC 5 new command
References sub_call_abs
Undelayed sub_call_cond
Short
List Command
Function Conditional call of an indexed subroutine: This command executes the command
sub_call( Index ), if the current IOvalue at the EXTENSION 1 connector's 16-bit digital
input port meets the following condition:
((IOvalue AND Mask1) = Mask1) AND (((not IOvalue) AND Mask0) = Mask0)
(i.e. if the bits specified in Mask1 are 1 and the bits specified in Mask0 are 0). Otherwise, the
directly following list command will be immediately executed.
Call
sub_call_cond( Mask1, Mask0, Index )
Parameters
Mask1,
Mask0
Index
Comments • See sub_call.
• Also see
® ®
RTC 4 RTC 5 new command
References sub_call
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
16-bit masks as unsigned 32-bit values
(only the least significant 16 bits are evaluated)
Index of the called indexed subroutine as an unsigned 32-bit value;
allowed range: [0 ... 1023]
"Conditional Command Execution", page
16-bit masks as unsigned 32-bit values
(only the least significant 16 bits are evaluated)
Index of the called indexed subroutine as an unsigned 32-bit value;
allowed range: [0 ... 1023]
"Conditional Command Execution", page
213.
213.
