Undelayed list_jump_cond
Short
List Command
Function Conditional (absolute) list jump: This command executes the command
list_jump_pos( Pos ), if the current IOvalue at the EXTENSION 1 connector's 16-bit digital
input port meets the following condition:
((IOvalue AND Mask1) = Mask1) AND (((not IOvalue) AND Mask0) = Mask0)
(i.e. if the bits specified in Mask1 are 1 and the bits specified in Mask0 are 0). Otherwise, the
directly following list command will be immediately executed.
Call
list_jump_cond( Mask1, Mask0, Pos )
Parameters
Mask1,
Mask0
Pos
Comments • The command is synonymous with the
there).
® ®
RTC 4 RTC 5 essentially unchanged functionality, however:
• extended range of Pos values
• Jumps into or out from the protected buffer area ("List 3") are not allowed (illegal jump
commands will be ignored during processing, also see list_jump_pos).
References list_jump_pos,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
16-bit masks as unsigned 32-bit values
(only the least significant 16 bits are evaluated)
absolute jump address [0 ... (2
list_jump_pos_cond
20
–1)] as an unsigned 32-bit value
list_jump_pos_cond command (see comments
