Ctrl Command config_laser_signals
Function configures the laser signal types to be outputted on pin 1 (LASER1), pin 2 (LASERON) and
pin 9 (LASER2) of the LASER connector.
Call
config_laser_signals( Config )
Parameter
Config
Comments • The specified configuration takes effect the next time the laser is switched on. There-
fore, the command shouldn't be issued during an active marking procedure.
Examples • Config = 000111
LASER1 channel, LASERON signal on LASER2 channel
In this configuration, LASER1 signals synchronously generated with the LASERON signal
can be immediately outputted, whereas the laser itself switches on only after a delay by
the FirstPulseKiller signal.
• Config = 100100
signal on the LASER1 channel, LASER2 signal on the LASER2 channel
In this configuration, LASER1 signals can only be switched on after the laser, not before
it (here the LASERON signal is the laser start signal; LASER1 signals can't be outputted
before the laser start, because the RTC
signal is on).
® ®
RTC 4 RTC 5 new command
Version info Available beginning with version DLL 533, OUT 534, RBF 524
Delayed short

config_laser_signals_list

list command
Function same as config_laser_signals, but a list command.
Call
config_laser_signals_list( Config )
Parameters
Config
• See config_laser_signals.
Comments
® ®
RTC 4 RTC 5 new command
Version info Available as of version DLL 537, OUT 537
References

config_laser_signals

®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
desired signal configuration as an unsigned 32-bit value
Thereby the following bits configure:
Bits # 0-1: Pin 2 (LASERON channel)
Bits # 2-3: Pin 1 (LASER1 channel)
Bits # 4-5: Pin 9 (LASER2 channel)
Bits # 6-31 are ignored
To the following signal type:
= 0 = 00 : LASERON signal
b
= 1 = 01 : LASER1 signal
b
= 2 = 10 : LASER2 signal
b
= 3 = 11 : FirstPulseKiller signal
b
The default setting (after load_program_file) is
Config = 100100
b
: FirstPulseKiller signal on LASERON channel, LASER1 signal on
b
(default setting): LASERON signal on the LASERON channel, LASER1
b
Siehe config_laser_signals.
= 0x24 = 36
®
5 only generates LASER1 signals if the LaserON
