16.3 Installation and Start-Up
For installing and starting-up an RTC
board and its software proceed as with an
®
RTC 5 PC interface board (see
Caution!
®
• The RTC 5-Express board does not support
power-saving modes that switch off power to
the PCI-Express bus. Accordingly, you must
disable standby or sleep modes of the operating
system. Particularly disable the WINDOWS sleep
mode option (some WINDOWS operating
systems enable this option by default). Also see
the note on page 27.
®
RTC 5 PC Interface Board
Rev. 1.9 e
®
16 Appendix B: The RTC 5-Express Board
16.4 Technical Specifications of
®
5-Express
page 56).
System Requirements
IBM-compatible PC with PCI-Express bus interface
Operating system
Dimensions
Length
Height
Interface to Scan System
PCI-Express x 1, version 1.0
"SPI / I2C" Connector
Connector
McBSP interface
2 Analog inputs (ANALOG IN0, ANALOG IN1):
• Input voltage range
• Input resistance
• ADC resolution
• Reference
Other Connectors and Specifications
Identical to RTC
®
RTC 5 PC/104-Plus Board
Microsoft (32 bit or 64 bit)
WINDOWS 8,
WINDOWS 7,
WINDOWS Vista and
WINDOWS XP (SP2 or
higher)
160 mm
104.5 mm
10-pin socket connector
identical to
®
RTC 5 PC interface board
(see page
0 V ... 10 V
4 k
12 bit
GND
®
5 PC interface board
52)
