WINDOWS Drivers
• RTC5DRV.sys, RTC5DRVx64.sys, RTC5DRVx86.sys
®
RTC 5 driver files
• RTC5DRV.inf
Installation file (setup information)
• RTC5DRV.cat, rtc5drvx64.cat, rtc5drvx86.cat
Security catalog files
• amd64/WdfCoInstaller01009.dll,
x86/WdfCoInstaller01009.dll
Installation assistant help files
• AfterInstallation/ScanlabClassChecker.cmd,
Security installation script with description in
ReadMe_ScanlabClassChecker.pdf
®
RTC 5 Files
• DLL Files:
– RTC5DLL.dll, RTC5DLLx64.dll
Win32- and Win64-based RTC
library
• Program Files:
– RTC5OUT.out
DSP program file
– RTC5RBF.rbf
Firmware file
– RTC5DAT.dat
Binary support file
• Utility Files for C, C++ and C#:
– RTC5DLL.lib, RTC5DLLx64.lib
Visual C++ import libraries for implicit linking of
the DLL for Win32-based and Win64-based
applications
– RTC5expl.c
C functions for DLL handling for explicit
linking
– RTC5expl.h
C function prototypes of the RTC5 for explicit
linking of the DLL
– RTC5impl.h
C function prototypes of the RTC5 for implicit
linking of the DLL
– RTC5impl.hpp
C++ function prototypes of the RTC5 for
implicit linking of the DLL
– RTC5Wrap.cs
Import declarations of the wrapper class for
implicit linking in C#
• Utility File for Delphi:
– RTC5Import.pas
Import declarations for Delphi
®
RTC 5 PC Interface Board
Rev. 1.9 e
1 Introduction
For easy identifying and archiving of different
software versions, the RTC
zipped:
• RTC5DAT_<Version>.zip
• RTC5DLL_<Version>.zip
(includes DLL and utility files)
• RTC5OUT_<Version>.zip
• RTC5RBF_<Version>.zip
Differing versions of the program files and DLL
cannot be arbitrarily combined with another. Each zip
file includes a text file with corresponding version
information.
Revision History
Description of changes in the RTC
• RTC5_Software_RevisionHistory_<Date>.pdf
Description in English
®
5 dynamic link
• RTC5_Software_Aenderungshistorie_<Date>.pdf
Description in German
Note
• Older RTC
include MS Visual Studio run time libraries for C
and C++. As of version DLL 527, these libraries are
no longer necessary.
®
5 files are also delivered
®
5 software
®
5 software packages additionally
