Ctrl Command stepper_rel_no
Function triggers set-position movements to the specified relative set positions via the desired
stepper motor output.
Call
stepper_rel_no( No, dPos, WaitTime )
Parameters
No
dPos
WaitTime
Comments • The desired set positions should be specified relative to the current internal set-position
values (the internal set-position values will correspondingly get newly set) and a set-
position movement will only be performed at the stepper motor output specified by No.
Otherwise the command is identical to
® ®
RTC 4 RTC 5 new command
Version info • See stepper_abs.
References stepper_abs_no, stepper_abs,
Undelayed stepper_rel_no_list
Short
List Command
Function same as
Call
stepper_rel_no_list( No, dPos )
Parameters
No
dPos
Comments • See stepper_rel_no.
• During performance of a reference movement (see stepper_init), execution of
stepper_rel_no_list will be delayed until the reference movement completes.
® ®
RTC 4 RTC 5 new command
Version info • Available beginning with version DLL 527, OUT 529, RBF 519
• For older RTC
the command is neither executed nor replaced by
RTC5_TYPE_REJECTED).
References stepper_rel_no
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
See stepper_abs_no.
Relative set position in CLOCK pulse units as a signed 32-bit value;
31
allowed range: [–2 ... +(2
See stepper_abs_no.
stepper_rel_no_list
stepper_rel_no (see above), but a list command and without WaitTime parameter
Number of the stepper motor output as an unsigned 32-bit value;
allowed values:
= 1: Stepper motor output 1
= 2: Stepper motor output 2
If the value is invalid, then the command will, already during loading, be
replaced by a list_nop (get_last_error
See stepper_rel_no.
®
5 boards with DSP version numbers < 2
31
-1)]
stepper_abs (see comments there).
return code RTC5_PARAM_ERROR).
(get_rtc_version
list_nop (get_last_error
bits #16-23),
return code:
