Ctrl Command stop_trigger
Function resets (to Busy= 0) a measurement session's status that can be queried via
measurement_status.
Call
stop_trigger()
Comments • This command is only needed if a measurement session was started via
set_trigger4, but not subsequently terminated via set_trigger(Period = 0) or
set_trigger4(Period = 0). Here, you can reset the measurement session's status even
when no list is active (see
• The command is ignored
board's BUSY status is currently set (list is being processed or has been halted via
pause_list) or the board's INTERNAL-BUSY status is currently set. In contrast, the
command is executed when a list has been paused via
® ®
RTC 4 RTC 5 new command
Version info Available beginning with version DLL 517, OUT 516, RBF 512
References measurement_status, set_trigger,
Undelayed store_encoder
Short
List Command
Function stores the current counts of the two RTC
Call
store_encoder( Pos )
Parameters
Pos
Comments • store_encoder can be used, for instance, to determine the exact number of encoder
increments occurring within a specific list-processing period. Here, you could begin the
command list by storing the counts in buffer position 0 via store_encoder(0). At the
end of the command list, you could store the counts to buffer position 1 via
store_encoder(1) and subsequently retrieve the stored values via read_encoder.
• The used buffer is reserved exclusively for storing encoder values.
• Also see
Signals", page
® ®
RTC 4 RTC 5 new command
Version info Available beginning with version DLL 520, OUT 519
References read_encoder, get_encoder, set_fly_x, set_fly_y, set_fly_rot,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
set_trigger
(get_last_error
set_trigger4
Choice of buffer position as an unsigned 32-bit value:
• Bit#0 = 0: The counter values will be stored in buffer position 0
• Bit#0 = 1: The counter values will be stored in buffer position 1
"Processing-on-the-fly (Optional)", page 177
215.
comments).
return code: RTC5_BUSY) if the addressed
set_wait (PAUSED status set).
®
5 encoder counters in a buffer on the RTC
and "Synchronization via Encoder
wait_for_encoder
set_trigger or
®
5.
