Ctrl Command release_rtc
Function releases the specified RTC
Call
NoOfReleasedCard = release_rtc( CardNo )
Parameter
CardNo
Result The returned (unsigned 32-bit) value is CardNo if the application was still in possession of
access rights for this board. Otherwise, 0 is returned.
Comments • After the application releases a board with release_rtc, it no longer has access rights
for this board. The board can then be subsequently acquired by the same or another
application via
• If a board released via release_rtc was the active board, then (other than multi-board
commands) only those non-multi-board commands not requiring explicit access rights
will be subsequently available. Another board will not be automatically selected as the
active board. Activation of another board (for which access rights are assigned to the
application) can be achieved via the
• The release_rtc command does not cause a reset of the RTC
only be initiated via the command
• The release_rtc command is also available without explicit access rights for a particular
®
RTC 5 board, but the command then has no effect (return value 0).
• The release_rtc command also has no effect (return value 0) if CardNo exceeds the
number of RTC
or if CardNo = 0 (real boards begin at 1).
• release_rtc is not available as a multi-board command.
® ®
RTC 4 RTC 5 new command
References acquire_rtc,
Ctrl Command release_wait
Function resumes execution of a list that was interrupted by a
Call
release_wait()
Comments • The command release_wait is only executed if the RTC
(hence if a wait marker was previously reached and execution was halted; the PAUSED
status is then set, the BUSY status is not set). Otherwise, the command is ignored
(get_last_error
• release_wait resets the PAUSED status and newly sets the BUSY status (both queriable
with get_status, also see
• The command release_wait resets to zero the wait_word that receives the wait marker
number during an interrupt.
• If a home jump (defined with
set_wait, then release_wait will lead to a corresponding home return (the INTERNAL-
BUSY status is set while the home return is executed).
• The wait status can be queried via get_wait_status.
® ®
RTC 4 RTC 5 essentially unchanged functionality, however:
®
the RTC
release_wait.
References set_wait, get_wait_status,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
®
5 for use by other applications (user programs)
(DLL-internal) number of the RTC
acquire_rtc (page 227)
®
5 boards found during initialization (see
init_rtc5_dll
return code RTC5_BUSY).
"List Execution Status", page
home_position
5 also provides a PAUSED status that will be set with
restart_list
®
5 board as an unsigned 32-bit value
or init_rtc5_dll (page 306).
select_rtc, page 403 command.
®
5 board. Board resets can
load_program_file, page 340.
rtc5_count_cards, page
set_wait command
®
5 is actually in a wait state
73).
or home_position_xyz) was executed via
set_wait
396)
and reset with
