Normal timed_jump_abs_3d
List Command
Function moves the output point (of the laser focus) for the specified jump duration along a 3D
vector from the current position to the specified position (absolute coordinate values)
within a three-dimensional process volume.
Restriction If the 3D option is not enabled or no 3D correction table has been assigned (see
select_cor_table), then the command will have the same effect as timed_jump_abs.
However, microvectorization will be calculated like a 3D command and hence will
influence the effective jump speed in the XY plane.
Call
timed_jump_abs_3d( X, Y, Z, T )
Parameters
X, Y, Z
T
Comments • Except for the additional motion in the third dimension, this command functions simi-
larly to the
above).
• The X and Y axes can be controlled with 20-bit resolution, the Z axis with 16-bit resolu-
tion. The RTC
upscales Z coordinate values internally to 20-bit values, so that the three dimensions of
space can be handled equivalently in terms of the supplied jump speed value.
• The DirectMove3D parameter of the
of Z-axis motion (linear or with stepwise correction).
• During calculation of the Z output value to the scan system, any previously defined
offset to the Z coordinate and focal length is taken into account (see
® ®
RTC 4 RTC 5 new command
®
In RTC 4 compatibility mode, the RTC
coordinates by 16 (the permissible range of values is correspondingly reduced). The value
range for Z coordinates is identical for the RTC
mode.
References timed_jump_abs, jump_abs_3d,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
absolute coordinates of the jump vector end point in bits as signed 32-bit
values; allowed range:
• for X and Y: [–8388608 ... 8388607] (out-of-range values will be edge-
clipped). The complete value range [–8388608 ... 8388607] is only usable
as a virtual image field e.g. for (enabled) Processing-on-the-fly applica-
tions. The current coordinates will be clipped to [–524288 ... 524287] (real
image field size) during runtime directly prior to use of the correction table.
• for Z: [–32768 ... 32767] (out-of-range values will be edge-clipped).
duration of the complete jump vector in microseconds (as a 64-bit IEEE
floating point value); allowed range: [0 ... 167772160]; the parameter will be
rounded to an integer-multiple of 10; out-of-range values will be clipped.
If T < 5, then timed_jump_abs_3d behaves like jump_abs_3d).
timed_jump_abs command (see the comments there, exception: T < 5, see
® ®
5 (in RTC 5 mode as well as in RTC
®
timed_jump_rel_3d
®
4 compatibility mode) automatically
set_delay_mode command determines the type
5 multiplies the specified value for the X and Y
®
5 mode and the RTC
page 126).
®
4 compatibility
