Delayed Short write_da_2_list
List Command
Function see write_da_x_list
Call
write_da_2_list( Value )
Parameter
Value
® ®
RTC 4 RTC 5 unchanged functionality
®
In RTC 4 compatibility mode: as
Ctrl Command write_da_x
Function writes an output value to one of the analog output ports of the RTC
Call
write_da_x( x, Value )
Parameters
x
Value
Comments • Also see
• The output range of the analog output ports is 0 V ... 10 V.
• For x < 1 or x > 2, the command is ignored
RTC5_PARAM_ERROR).
• The commands
(without parameter x).
® ®
RTC 4 RTC 5 unchanged functionality
®
In RTC 4 compatibility mode, the RTC
analog outputs only had 10-bit resolution).
Delayed Short write_da_x_list
List Command
Function same as
Call
write_da_x_list( x, Value )
Parameters
x
Value
Comments • For x < 1 or x > 2, the command is replaced with a
code RTC5_PARAM_ERROR).
® ®
RTC 4 RTC 5 unchanged functionality
®
In RTC 4 compatibility mode: as
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
12-bit output value for the ANALOG OUT2 analog output port as an unsigned
32-bit value. Higher bits are ignored.
Value = 0 corresponds to an output value of 0 V,
12
Value = 2 –1 to an output value of 10 V.
write_da_x
Number of the analog output port as an unsigned 32-bit value.
Allowed range: [1, 2] (1: ANALOG OUT1, 2: ANALOG OUT2)
12-bit output value for the selected analog output port as an unsigned 32-bit
value. Higher bits are ignored.
Value = 0 corresponds to an output value of 0 V,
12
Value = 2 –1 to an output value of 10 V.
"12-Bit Analog Output Ports", page
write_da_1 / write_da_2
write_da_x (see above), but a list command
Number of the analog output port as an unsigned 32-bit value.
Allowed range: [1, 2] (1: ANALOG OUT1, 2: ANALOG OUT2)
12-bit output value for the selected analog output port as an unsigned 32-bit
value. Higher bits are ignored.
Value = 0 corresponds to an output value of 0 V,
12
Value = 2 –1 to an output value of 10 V.
write_da_x
204.
(get_last_error return code
can be used alternatively to write_da_x
®
5 multiplies the specified Value by 4 (the RTC
list_nop (get_last_error
®
5.
®
4's
return
558
