15.3.4 Install ng the Drivers and the
®
RTC 5 Software
®
RTC 5 PC/104-Plus boards use the same drivers and
other software files as the RTC
Installation is also identical to the RTC
board (see page 57 and page
Notes
®
• Windows runs the RTC
PCI board.
• To install the driver, make sure you are logged on
with administrator rights (not necessary when
®
later using the RTC 5 PC/104-Plus board).
Caution!
®
• The RTC 5 PC/104-Plus board does not support
power-saving modes that switch off power to
the PCI bus. Accordingly, you must disable
standby or sleep modes of the operating
system. Particularly disable the WINDOWS sleep
mode option (some WINDOWS operating
systems enable this option by default). Also see
the note on page 27.
®
RTC 5 PC Interface Board
Rev. 1.9 e
®
15 Appendix A: The RTC 5 PC/104-Plus Board
®
5 PC interface board.
®
5 PC interface
58).
5 PC/104-Plus board as a
15.3.5 Functionality Test, User Appli-
cations and Demo Software
The HPGL conversion program HPGL.EXE is supplied
for testing control of the scan system (see
Application programming is identical to that of the
®
RTC 5 PC interface board (see
the same demo programs used for the
®
RTC 5 PC interface board.
Danger!
!
• Always turn on the controller with
®
RTC 5 PC/104-Plus board and the power
supply for the scan system first before
turning on the laser. Otherwise, there is the
danger of uncontrolled deflection of the
laser beam.
Caution!
• Carefully check your application program before
running it. Programming errors can cause a
system breakdown. In this case, neither the laser
nor the scan head can be controlled.
page 59).
page 59). You can run
