Ctrl Command set_mcbsp_y
Function activates or deactivates Y offset correction for online positioning via the McBSP interface.
Call
set_mcbsp_y( Scale )
Parameter
Scale
Comments • For online positioning, see
• With an McBSP input value of Y
apply_mcbsp
YOffset (in bits) = Scale
YOffset values outside of [–524288 ... +524287] will be clipped to the boundaries as
long as Scale
• The McBSP interface can't be simultaneously used for both online positioning and
Processing-on-the-fly applications (see
® ®
RTC 4 RTC 5 new command
Version info Available beginning with version DLL 524, OUT 526
References set_mcbsp_y_list, set_mcbsp_x, set_mcbsp_rot,
Undelayed set_mcbsp_y_list
Short
List Command
Function same as
Call
set_mcbsp_y_list( Scale )
Parameter
Scale
Comments • See set_mcbsp_y.
® ®
RTC 4 RTC 5 new command
Version info Available beginning with version DLL 524, OUT 526
References set_mcbsp_y
Ctrl Command set_multi_mcbsp_in
Function activates a Processing-on-the-fly application and McBSP multi transmission with up to
eight different data types.
Restriction If the Processing-on-the-fly option is not enabled, then the command switches off the
Processing-on-the-fly process (even if it was never switched on).
Call
set_multi_mcbsp_in( Ctrl, P, Mode )
Parameter
Ctrl
P
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
Value as a 64-bit IEEE floating point number:
–26 26
2 < Scale < 2 : scaling factor (correction will be activated)
otherwise: correction will be deactivated
page
in
will function like set_offset( ..., YOffset, ... ), whereby
·
Y
in
·
Y doesn't exceed the value range ±2
in
set_mcbsp_y (see above), but a list command
See set_mcbsp_y.
control parameter for initializing or deactivating laser power variation as an
unsigned 32-bit value:
= 1...6: defines which signal parameter to vary: for a description, see
set_auto_laser_control.
= 0 or > 6: deactivates laser power variation (if Ctrl > 6:
return code RTC5_PARAM_ERROR).
Initialization value for laser power as an unsigned 32-bit value. For the
allowed range, see set_auto_laser_control.
165.
for the Y offset correction, the command
31
.
page 166).
apply_mcbsp
get_last_error
