Pin at MULTI Signal
connector
ANALOG OUT2
B14
A49, A50 RxD, TxD
A41 - A46 CLKX0, CLKR0,
FSX0, FSR0, DX0,
DR0
B16 SWITCH1/2,
ENABLE1/2,
DIRECTION1/2,
CLOCK1/2
A37, A38, B1 (B40, +5 V
B42)
+3.3 V
A47
GND
A39, A40, A48, B2,
B15, B24, B25, B43,
B50 (B40, B42)
B45, B46
®
RTC 5 PC Interface Board
Rev. 1.9 e
®
15 Appendix A: The RTC 5 PC/104-Plus Board
Signal description
12-bit analog output port
(the signal is also available via the LASER
connector – see page 580. Jumpers
JP10+JP12 on the back side of the
®
RTC 5 PC/104-Plus board allow setting how
the 10 V maximum output voltage is
generated – see page 585).
RS232 interface
McBSP interface
signals for controlling two stepper motors
5 V output signal level
(optionally at B40, B42, dependent on the
JP2-JP8 jumper configuration, see
page 586)
3,3 V output signal level
CPU ground
(optionally at B40, B42, dependent on the
JP2-JP8 jumper configuration, see
page 586)
internally connected with each other
®
Connector on RTC 5
PC interface board
"MARKING ON THE FLY
Connector", page 51
and
"Laser Connector", page
46
"RS232" (see page 51)
"SPI / I2C"
(see page 52)
"STEPPER MOTOR"
(see page 53)
EXTENSION 1,
EXTENSION 2,
MARKING ON THE FLY
"SPI / I2C"
EXTENSION 1,
EXTENSION 2,
MARKING ON THE FLY,
"RS232",
"STEPPER MOTOR",
"SPI / I2C"
EXTENSION 2,
"RS232"
